System And Components
293-4138 COMBUSTION GP-EXHAUSTS/N LEE1716-UP
Group No: 293-4138
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 2 | |
| 3008688 | 2 CLAMP-BAND | 1 | |
| 2856393 | 3 CLIP (LADDER) | 1 | |
| 2872886 | 5 TUBE AS | 1 | |
| 2890728 | 6 NUT (M8X1.25-THD) | 2 | |
| 2893107 | 7 GASKET | 1 | |
| 2901393 | 9 BRACKET AS-SUPPORT | 1 | |
| 2902102 | 10 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 2903930 | 11 BOLT (M8X1.25X55-MM) | 2 | |
| 2956240 | 12 WIRE AS | 1 | |
| 3003724 | 13 COMBUSTION GP-EXHAUST | 1 | |
| 2953099 | 14 SPARK PLUG (AFTERTREATMENT REGEN DEVICE) | 1 | |
| 6V2317 | 15 BOLT (M8X1.25X30-MM) | 3 | |
| 2901993 | 17 STRAP-CABLE | 6 | |
| 2916641 | 18 CLIP | 1 | |
| 3T0849 | 19 BOLT-SOCKET HEAD (M6X1X25-MM) | 2 | |
| 6V5215 | 21 BOLT (M8X1.25X16-MM) | 1 | |
| 7X2619 | 22 BOLT (M6X1X10-MM) | 1 | |
| 9M1974 | 23 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 9X8256 | 24 WASHER (6.6X12X2-MM THK) | 3 | |
| 2886818 | 25 SENSOR-TEMPERATURE | 1 | |
| 2886820 | 26 SENSOR AS-TEMPERATURE | 1 | |
| 3E4352 | 30 WASHER-HARD (8.8X20.5X2.5-MM THK) | 7 | |
| 2771873 | 31 CLIP (LADDER) | 2 | |
| 2041611 | 32 STRAP-CABLE (DUAL) | 2 | |
| 5P7970 | 33 NUT (M8X1.25-THD) | 2 |
