System And Components
174-8775 LINES GP-TURBOCHARGER OILS/N 2AF1-719
Group No: 174-8775
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W7214 | 1 ELBOW-DRAIN | 2 | |
| 4P0692 | 2 CLAMP AS | 6 | |
| 1081434 | GROMMET | 1 | |
| 4P4460 | 3 GASKET | 2 | |
| 6I0804 | 4 ADAPTER-TURBOCHARGER OIL (RH, SUPPLY) | 1 | |
| 6I0805 | 5 ADAPTER-TURBOCHARGER OIL (LH, SUPPLY) | 1 | |
| 2528374 | 6 GASKET | 2 | |
| 7N7559 | 7 GASKET | 2 | |
| 7W6333 | 8 SPACER (10.5X20X10.7-MM THK) | 4 | |
| 1134646 | 9 TUBE AS | 1 | |
| 1134648 | 10 ELBOW (RH, OIL DRAIN) | 1 | |
| 1169863 | 11 BRACKET | 1 | |
| 1748773 | 12 TUBE AS | 1 | |
| 1748774 | 13 TUBE AS | 1 | |
| 1791508 | 14 ELBOW (LH, OIL DRAIN) | 1 | |
| 1855855 | 15 TUBE | 1 | |
| 0307964 | 16 ELBOW | 1 | |
| 0L1143 | 17 BOLT (3/8-16X2.5-IN) | 3 | |
| 0S1590 | 18 BOLT (3/8-16X2-IN) | 2 | |
| 0S1594 | 19 BOLT (3/8-16X1-IN) | 4 | |
| 0T0573 | 20 BOLT (3/8-16X2.75-IN) | 2 | |
| 1A5964 | 21 BOLT (3/8-16X4.5-IN) | 4 | |
| 2P1296 | 22 TEE | 1 | |
| 2P7636 | 23 CONNECTOR (3/4-16 STR-THD) | 2 | |
| 5M2894 | 24 WASHER-HARD (10.2X18.5X2.5-MM THK) | 11 | |
| 5P9890 | 25 SEAL-O-RING | 4 | |
| 6V4589 | 26 SEAL-O-RING | 1 | |
| 8L2786 | 27 SEAL-O-RING | 2 | |
| 9S8752 | 28 NUT-FULL (3/8-16-THD) | 3 | |
| 9X6458 | 29 WASHER-HARD (10.2X22.5X3-MM THK) | 1 |
