System And Components
385-6695 LINES GP-TURBOCHARGER AIRS/N WF21-UP
Group No: 385-6695
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7C7909 | 1 ELBOW (AIR INLET) | 10 | |
| 7C7910 | 2 ELBOW (AIR INLET) | 2 | |
| 7C8199 | 3 FLANGE | 12 | |
| 7N5080 | 4 GASKET-MANIFOLD | 12 | |
| 7W3145 | 5 PLATE | 4 | |
| 1097411 | 6 SEAL-O-RING | 4 | |
| 2858436 | 7 COVER (AIR INLET) | 1 | |
| 1277103 | 8 SPACER (FLANGE) | 2 | |
| 3485661 | 9 PLATE | 1 | |
| 1679528 | 10 TUBE-AIR (RH) | 1 | |
| 1679529 | 11 TUBE-AIR (LH) | 1 | |
| 2839599 | 12 MANIFOLD (AIR INLET) | 1 | |
| 0L1351 | 13 BOLT (3/8-16X0.875-IN) | 4 | |
| 0S0509 | 14 BOLT (3/8-16X0.75-IN) | 30 | |
| 0S1590 | 15 BOLT (3/8-16X2-IN) | 6 | |
| 0S1594 | 16 BOLT (3/8-16X1-IN) | 8 | |
| 0T0573 | 17 BOLT (3/8-16X2.75-IN) | 4 | |
| 1T0720 | 18 BOLT-12 POINT HEAD (3/8-16X1.25-IN) | 48 | |
| 2A4639 | 19 BOLT (3/8-16X1.625-IN) | 24 | |
| 4S5898 | 20 SEAL-O-RING | 12 | |
| 5M2894 | 21 WASHER-HARD (10.2X18.5X2.5-MM THK) | 116 | |
| 6V2605 | 22 STUD-TAPERLOCK (3/8-16X3.59-IN) | 4 | |
| 6V3917 | 23 SEAL-O-RING | 4 | |
| 6V5101 | 24 SEAL-O-RING | 12 | |
| 6V5103 | 25 SEAL-O-RING | 4 | |
| 8M9024 | 26 WASHER-HARD (10.2X22.5X5-MM THK) | 8 | |
| 8T6762 | 27 PLUG-PIPE (1/2-14-THD) | 5 | |
| 9F2773 | 28 BOLT (3/8-16X8.5-IN) | 10 | |
| 9S8752 | 29 NUT-FULL (3/8-16-THD) | 4 |
