System And Components
205-5945 BEAM & SCRAPER GP-DISC -TL3 730 RIGID FRAMES/N DRC1-UP
Group No: 205-5945
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2055429 | 1 BEAM AS-FRONT (RH) | 1 | |
| 2055430 | BEAM AS-FRONT (LH) | 1 | |
| 2055431 | BEAM AS-REAR (RH) | 1 | |
| 2055432 | BEAM AS-REAR (LH) | 1 | |
| 2055876 | 2 PIVOT AS | 4 | |
| 2036314 | 3 SLEEVE-WEAR | 16 | |
| 3B4641 | 4 PIN-COTTER | 8 | |
| 2055877 | 5 PIN | 8 | |
| 2055878 | 6 PIN-CLEVIS | 2 | |
| 2026734 | 7 PIN-COTTER | 2 | |
| 2055971 | 8 ARM AS | 2 | |
| 2055880 | 9 WASHER | 2 | |
| 2024507 | 10 LOCKNUT | 2 | |
| 2030185 | 11 PIN | 2 | |
| 2055881 | 12 PIVOT AS | 2 | |
| 2036371 | 13 RING | 24 | |
| 2036370 | 14 BEARING AS | 12 | |
| 8T9313 | 15 BOLT (3/4-10X7-IN) | 24 | |
| 2036368 | 16 HOUSING-BEARING | 12 | |
| 2036369 | 17 HOUSING-BEARING | 12 | |
| 2036374 | 18 FITTING-GREASE | 12 | |
| 2022853 | 19 WASHER | 24 | |
| 2023537 | 20 LOCKWASHER | 24 | |
| 6V8182 | 21 NUT (3/4-10-THD) | 24 | |
| 2036378 | 22 U-BOLT | 12 | |
| 4B4281 | 23 WASHER (16.8X33X2.5-MM THK) | 24 | |
| 2022859 | 24 LOCKWASHER | 24 | |
| 7X0448 | 25 NUT (5/8-11-THD) | 24 | |
| 2036372 | 26 ARM AS (LH) | 6 | |
| 2036373 | 27 ARM AS (RH) | 6 | |
| 2023536 | 28 U-BOLT | 24 | |
| 2036375 | 29 PLATE | 12 | |
| 2036376 | 30 SHANK | 12 | |
| 2036377 | 31 PLATE | 12 | |
| 2027574 | 32 SLEEVE-WEAR | 8 | |
| 2036005 | 33 SLEEVE-WEAR | 4 | |
| 2036382 | 34 BLADE-SCRAPER (FRONT, LH; REAR, RH) | 17 | |
| 2036383 | 35 BLADE-SCRAPER (RH FRONT, LH REAR) | 17 | |
| 6V8188 | 36 NUT (1/2-13 THD) | 68 | |
| 2022875 | 37 LOCKWASHER | 68 | |
| 2056548 | 38 PLATE | 34 | |
| 2036379 | 39 U-BOLT | 34 | |
| 2076882 | 40 TUBE (104-IN) | 2 | |
| 2076883 | TUBE (108.5-IN) | 2 | |
| 2129664 | 41 NUT | 8 |
