System And Components
205-1804 FRAME GP-FOLDING -TL3 930S/N DRD1-UP
Group No: 205-1804
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2051791 | 1 FRAME AS | 1 | |
| 2051792 | 2 FRAME AS (LH) | 1 | |
| 2051793 | 3 FRAME AS (RH) | 1 | |
| 2036003 | 4 SLEEVE-WEAR | 12 | |
| 2027574 | 5 SLEEVE-WEAR | 4 | |
| 2036004 | 6 SLEEVE-WEAR | 8 | |
| 2036005 | 7 SLEEVE-WEAR | 8 | |
| 2036314 | 8 SLEEVE-WEAR | 16 | |
| 2078171 | 9 LOCK PIN | 6 | |
| 2051794 | 10 PIN | 6 | |
| 2036366 | 11 WASHER | 4 | |
| 2024507 | 12 LOCKNUT | 6 | |
| 3B5328 | 13 PIN-COTTER | 6 | |
| 2026729 | 14 CLAMP-HOSE | 1 | |
| 2026728 | 15 CANISTER-STORAGE (LITERATURE) | 1 | |
| 2051795 | 16 WRENCH (TIE ROD) | 1 | |
| 2051796 | 17 STOP AS | 2 | |
| 2051797 | 18 BOLT-GRADE 5 | 4 | |
| 2022859 | 19 LOCKWASHER | 4 | |
| 7X0448 | 20 NUT (5/8-11-THD) | 4 | |
| 2040424 | 21 U-BOLT | 4 | |
| 2022875 | 22 LOCKWASHER | 8 | |
| 6V8188 | 23 NUT (1/2-13 THD) | 8 | |
| 2051798 | 24 EXTENSION AS | 4 | |
| 2051818 | 25 BOLT-GRADE 5 | 16 | |
| 2024361 | 26 LOCKWASHER | 16 | |
| 6V8190 | 27 NUT (1-8-THD) | 16 | |
| 2036007 | 28 BRACKET | 1 | |
| 2036006 | 29 BOLT-CARRIAGE | 1 | |
| 2036008 | 30 LOCKWASHER | 1 | |
| 3S1546 | 31 NUT-FULL (7/16-14 THD) | 1 | |
| 2051800 | 32 PLATE AS-WARNING (SLOW MOVING VEHICLE) | 1 | |
| 2036336 | 33 FITTING-GREASE | 10 | |
| 2051801 | 34 EYEBOLT | 2 | |
| 2B2571 | 35 NUT-JAM (1-1/4-7-THD) | 4 | |
| 2051802 | 36 PIN-ROLL | 2 | |
| 2051803 | 37 LOCK AS | 2 | |
| 2030185 | 37A PIN | 1 |
