System And Components
213-3501 HITCH GP -TL4 27,31,36,42,45S/N SFB1-UP; SFC1-UP; SFD1-UP; SFE1-UP; SFF1-UP
Group No: 213-3501
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2129385 | 1 FRAME AS | 1 | |
| 2029971 | 2 CLEVIS | 1 | |
| 2029972 | 3 BUSHING | 1 | |
| 2029970 | 4 PIN-HITCH | 1 | |
| 2051870 | 5 HITCH AS | 1 | |
| 7X0350 | 6 BOLT (5/8-11X3.50 IN) | 3 | |
| 2026734 | 7 PIN-COTTER | 1 | |
| 2029973 | 8 PIN-CLEVIS | 1 | |
| 3K2889 | 9 LOCKNUT (5/8-11 THD) | 3 | |
| 2051866 | 10 PIN-HITCH | 1 | |
| 2051868 | 11 WASHER-SPECIAL | 1 | |
| 2023537 | 12 LOCKWASHER | 1 | |
| 2051869 | 13 BOLT-GRADE 5 | 1 | |
| 2051867 | 14 CHAIN | 1 | |
| 6V8190 | 15 NUT (1-8 THD) | 2 | |
| 2024361 | 16 LOCKWASHER | 2 | |
| 2051872 | 17 PLATE AS | 2 | |
| 2051875 | 18 SPRING | 2 | |
| 2077602 | 19 WASHER | 2 | |
| 2051874 | 20 BOLT-GRADE 5 | 2 | |
| 2036308 | 21 JACK AS | 1 | |
| 2036309 | 22 U-BOLT | 2 | |
| 2036310 | 23 BRACKET AS | 1 | |
| 2022875 | 24 LOCKWASHER | 4 | |
| 6V8188 | 25 NUT (1/2-13 THD) | 4 | |
| 2039373 | 26 PIN | 1 | |
| 3B4629 | 27 PIN-COTTER | 1 | |
| 2129400 | 28 PIN AS | 2 | |
| 1J8136 | 29 PIN-SPRING | 2 | |
| 2129401 | 30 STRAP AS | 2 | |
| 2029957 | 31 END | 1 | |
| 9S8216 | 32 NUT-full (1-1/2-6 THD) | 1 | |
| 2023553 | 33 FITTING-GREASE | 2 | |
| 2129402 | 34 TUBE AS | 1 | |
| 2036312 | 35 END | 1 | |
| 2051873 | 36 PIN-PIVOT | 2 | |
| 2051871 | 37 BOLT-GRADE 5 | 2 | |
| 2036321 | 38 SLEEVE-WEAR | 4 | |
| 2039372 | 39 PIN-ROLL | 4 | |
| 2029967 | 40 SLEEVE-WEAR | 4 | |
| 2029968 | 41 PIN | 4 | |
| 4H6996 | 42 PIN-SPRING | 8 | |
| 1D5119 | 43 NUT (3/4-10 THD) | 2 |
