213-3702 CYLINDER & LINES GP-LIFT -WHEEL-TL4 36S/N SFD1-UP

Group No: 213-3702
Part NumberPart NameQty
20679011 HOSE AS1
20679002 HOSE AS1
21073463 FITTING1
20396914 LOCK GP-TRANSPORT (WHEELS)1
20396885 CONNECTOR GP2
3K0360SEAL-O-RING1
8M0505CONNECTOR1
21312296 HOSE AS1
21312287 HOSE AS1
20679068 VALVE GP-REMOTE BYPASS (DEPTH STOP)1
2080974SPOOL AS1
3K0360SEAL-O-RING1
2080976PLUG1
11847289 ELBOW13
213122710 HOSE AS1
213123211 HOSE AS1
213123112 HOSE AS1
206793913 HOSE AS1
213123614 HOSE AS2
206794315 HOSE AS4
213122016 BRACKET2
032127017 TEE2
202269418 CYLINDER GP-LIFT (4.25 IN BORE X 10 IN STROKE)(WHEEL)(REPHASING)2
202269519 CYLINDER GP-LIFT (4 IN BORE X 10 IN STROKE)(WHEEL)(REPHASING)2
208354120 CYLINDER GP-LIFT (3.75 IN BORE X 10 IN STROKE)(WHEEL)(REPHASING)2
213121821 CLAMP-HOSE8
210736222 U-BOLT8
206449023 LOCKWASHER18
6V880124 NUT (3/8-16 THD)18
5P816725 BOLT (3/8-16X0.625 IN)3
6V818226 NUT (3/4-10 THD)2
202353727 LOCKWASHER2
4L645428 BOLT (3/8-16X1 IN)2
7X036629 BOLT (3/4-10X2 IN)2
203017630 CLIP11
203019531 CONNECTOR2
211322332 COUPLER2
206448833 BOLT-GRADE 52
203970634 LOCKNUT2
211544235 BRACKET1
211544336 U-BOLT1
202285937 LOCKWASHER2
202286038 NUT2
203706439 BOLT-GRADE 52
211544440 NUT-FLANGE2
203968741 CLIP2
206792142 BRACKET AS1
202354543 PIN-COTTER1
202983844 STRAP-TIE24
2050890KIT-SEAL (WHEEL LIFT CYL/4.25 IN BORE)1
2050889KIT-SEAL (WHEEL LIFT CYL/4 IN BORE)1
