System And Components
214-7616 DISC GP-BLADE -OUTER WING-TL4 36S/N SFD1-UP
Group No: 214-7616
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2129746 | 1 ARM AS-BEARING | 2 | |
| 2129722 | 2 U-BOLT | 4 | |
| 2023537 | 3 LOCKWASHER | 8 | |
| 6V8182 | 4 NUT (3/4-10 THD) | 8 | |
| 2129745 | 5 SPOOL-half | 2 | |
| 2129747 | 6 SPOOL-half | 2 | |
| 2129749 | 7 SPOOL-SPACER | 4 | |
| 2129751 | 8 WASHER-END | 1 | |
| 2129744 | 9 WASHER-END | 1 | |
| 2129701 | 10 TIE ROD | 1 | |
| 2129748 | 11 BLADE-DISC (20 IN) | 7 | |
| 2129743 | 12 NUT-SLOTTED | 2 | |
| 1J8136 | 13 PIN-SPRING | 1 | |
| 2075065 | 14 PIN-COTTER | 1 | |
| 1D4688 | 15 BOLT (1/2-13X1.5IN) | 8 | |
| 2129692 | 16 BEARING AS | 2 | |
| 2022875 | 17 LOCKWASHER | 8 | |
| 6V8188 | 18 NUT (1/2-13 THD) | 8 |
