System And Components
214-7611 SCRAPER GP-DISC -LH WING-TL4 27,31,36,42,45S/N SFB1-UP; SFC1-UP; SFD1-UP; SFE1-UP; SFF1-UP
Group No: 214-7611
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2129734 | 1 BEAM AS-GANG (68 IN) | 1 | |
| 2129736 | 2 U-BOLT | 7 | |
| 2129738 | 3 BLADE-SCRAPER LH | 7 | |
| 2129739 | 4 CLAMP | 7 | |
| 2022875 | 5 LOCKWASHER | 14 | |
| 6V8188 | 6 NUT (1/2-13 THD) | 14 | |
| 8C8843 | 7 BOLT (1-8X4.5 IN) | 2 | |
| 8T5361 | 8 WASHER-HARD (28X49X5MM THK) | 2 | |
| 2129714 | 9 NUT | 2 | |
| 2023545 | 10 PIN-COTTER | 2 |
