System And Components
211-4813 CYLINDER & LINES GP-LIFT -WHEEL-TL5 48,50S/N FCL1-UP; FCM1-UP
Group No: 211-4813
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2022694 | 1 CYLINDER GP-LIFT (WHEEL)(REPHASING) | 2 | |
| 2022695 | 2 CYLINDER GP-LIFT (WHEEL)(REPHASING) | 2 | |
| 2083541 | 3 CYLINDER GP-LIFT (3.75-IN BOREX10-IN STROKE)(WHEEL)(REPHASING) | 2 | |
| 2067900 | 4 HOSE AS | 1 | |
| 2067901 | 5 HOSE AS | 1 | |
| 2107011 | 6 HOSE AS | 1 | |
| 2107347 | 7 HOSE AS | 1 | |
| 2107351 | 8 HOSE AS | 2 | |
| 2067942 | 9 HOSE AS | 1 | |
| 2107352 | 10 HOSE AS | 1 | |
| 2114452 | 11 HOSE AS | 1 | |
| 2114454 | 12 HOSE AS | 1 | |
| 2114455 | 13 HOSE AS | 2 | |
| 2067915 | 14 HOSE AS | 2 | |
| 2107353 | 15 HOSE AS | 2 | |
| 2114847 | 16 HOSE AS | 2 | |
| 2107346 | 17 FITTING | 1 | |
| 2039691 | 18 LOCK GP-TRANSPORT (WHEELS) | 1 | |
| 2039688 | 19 CONNECTOR GP | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 8M0505 | CONNECTOR | 1 | |
| 2030195 | 20 CONNECTOR | 2 | |
| 0321270 | 21 TEE | 2 | |
| 1184728 | 22 ELBOW | 12 | |
| 2030195 | 23 CONNECTOR | 4 | |
| 2107361 | 24 CLAMP-HOSE | 2 | |
| 2107362 | 25 U-BOLT | 2 | |
| 2114848 | 26 CLAMP-HOSE | 7 | |
| 2107363 | 27 U-BOLT | 11 | |
| 2107364 | 28 CLAMP-HOSE | 6 | |
| 5S7383 | 29 BOLT (3/8-16X1.75-IN) | 4 | |
| 2064490 | 30 LOCKWASHER | 30 | |
| 9S8752 | 31 NUT-FULL (3/8-16-THD) | 30 | |
| 2114850 | 32 BRACKET | 2 | |
| 2114851 | 33 U-BOLT | 2 | |
| 2022859 | 34 LOCKWASHER | 6 | |
| 7X0448 | 35 NUT (5/8-11-THD) | 6 | |
| 2029838 | 36 STRAP-TIE | 26 | |
| 2113223 | 37 COUPLER | 2 | |
| 2067921 | 38 BRACKET AS | 1 | |
| 2023545 | 39 PIN-COTTER | 1 | |
| 2030176 | 40 CLIP | 3 | |
| 9B7237 | 41 BOLT (3/8-16X1.25-IN) | 4 | |
| 2039706 | 42 LOCKNUT | 4 | |
| 2115442 | 43 BRACKET | 1 | |
| 2115443 | 44 U-BOLT | 1 | |
| 2037064 | 45 BOLT-GRADE 5 | 2 | |
| 2115444 | 46 NUT-FLANGE | 2 | |
| 2039687 | 47 CLIP | 3 | |
| 2050890 | KIT-SEAL (WHEEL LIFT CYL/4.25 IN BORE) | 1 | |
| 2050889 | KIT-SEAL (WHEEL LIFT CYL/4 IN BORE) | 1 |
