Assembly
100%

545-5958 COUPLER GP-QUICKPART OF 558-8926, 567-6086 TILT GP-ROTATOR

Group No: 545-5958
Part NumberPart NameQty
51131811 CYLINDER GP-COUPLER1
51131832 ROD2
51582503 LIGHTING GP (LED)1
12931784 LOCKNUT (M6X1-THD)2
14360205 BOLT-SOCKET HEAD (M6X1X75-MM)2
17051216 ADAPTER AS2
4J5477SEAL-O-RING1
1626816SEAL1
3779597ADAPTER1
18830937 SCREW-FLAT HEAD (M20X2.5X50-MM)4
19175038 BOLT (M12X1.75X16-MM)2
31334809 ELBOW AS6
4J5477SEAL-O-RING1
4J9535SEAL-O-RING1
2815959RING-RETAINING1
3133479ELBOW1
4H144010 PIN-SPRING2
511318011 PIN2
511844812 LOCKWASHER3
516058213 BEARING-ALIGNING2
517041214 PLATE2
545595915 HOUSING GP-COUPLER1
545596016 CYLINDER GP-COUPLER1
545596117 HOSE AS2
545596218 HOSE AS2
545596319 BRACKET1
545596420 PIN2
545596521 BRACKET2
6C904822 NUT (M8X1-THD)4
6V568323 BOLT (M6X1X16-MM)3
8T026924 BOLT-SOCKET HEAD (M6X1X20-MM)2
8T239425 BOLT-SOCKET HEAD (M8X1.25X90-MM)4
