Assembly
100%

323-6079 JAW GP-COMBINATIONS/N ZYW1-UP

Group No: 323-6079
Part NumberPart NameQty
16903711 PIN1
16903782 SPACER (128X139X30-MM THK)1
16903793 SHIM (2.5-MM THK)2
16903804 SHIM (3-MM THK)2
16903815 SHIM (3.5-MM THK)2
31313056 TOOTH3
16903857 EDGE-CUTTING4
16903868 SHIM (1-MM THK)12
16903889 SHIM (1.5-MM THK)4
169345510 BUSHING2
169606611 EDGE-CUTTING1
169607212 SHIM (1-MM THK)5
169607313 SHIM (1.5-MM THK)1
323608014 JAW AS (LOWER)1
318173114A PLATE-WEAR1
323608115 JAW AS (UPPER)1
319157515A BAR-WEAR1
145407516 BOLT (M20X2.5X75-MM)12
159112217 LOCKWASHER3
7X245418 BOLT (M24X3X110-MM)3
7X257519 BOLT (M24X3X60-MM)2
7Y524120 BOLT-SOCKET HEAD (M20X2.5X60-MM)2
8T395721 BOLT-SOCKET HEAD (M12X1.75X30-MM)6
8T400122 NUT (M24X3-THD)5
8T412323 WASHER (3.62X5.75X0.375-MM THK)14
8T413124 NUT (M20X2.5-THD)12
347249525 HOLDER-TOOTH1
347249426 HOLDER-TOOTH1
