System And Components
108-8873 IGNITION GP-GAS ENGINES/N 4DL1-38
Group No: 108-8873
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9M1974 | 1 WASHER-HARD (8.8X16X2-MM THK) | 11 | |
| 2W3747 | 2 TRANSFORMER AS | 6 | |
| 2N2839 | 3 PLUG AS-SPARK | 6 | |
| 8M8157 | 4 SEAL-O-RING | 6 | |
| 1107894 | 5 SHIELD-HEAT | 1 | |
| 1107892 | 6 SUPPORT | 1 | |
| 1107893 | 7 SUPPORT | 1 | |
| 0S1618 | 8 BOLT (5/16-18X1-IN) | 10 | |
| 6V3964 | 9 WASHER-HARD (8.8X25.5X5-MM THK) | 16 | |
| 5S0003 | 10 NUT (5/16-18-THD) | 8 | |
| 1220033 | 11 HARNESS AS-POWER | 1 | |
| 1106067 | 12 PLATE-CONTROL | 1 | |
| 7B8167 | 13 BOLT (1/4-20X1.625-IN) | 4 | |
| 5P0537 | 14 WASHER-HARD (7.2X14.5X2-MM THK) | 12 | |
| 9S8750 | 15 NUT-FULL (1/4-20-THD) | 12 | |
| 7E3222 | 16 MOUNT-FLEXIBLE | 4 | |
| 1012817 | 17 CONTROL GP-RELAY | 1 | |
| 1107895 | 18 SENSOR GP-SPEED | 1 | |
| 3K0360 | 19 SEAL-O-RING | 1 | |
| 9W0532 | 20 SENSOR GP-TEMPERATURE | 1 | |
| 1112351 | 21 SENSOR GP-PRESSURE | 1 | |
| 9X1813 | SLEEVE (34 CM LG) | ||
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 3E3368 | WEDGE-PLUG LOCK (3-PIN) | 1 | |
| 1028808 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 6B5072 | 22 ADAPTER | 1 | |
| 6V5048 | 23 SEAL-O-RING | 1 | |
| 9X0435 | 24 ADAPTER | 1 | |
| 4P7581 | 25 CLIP (LADDER) | 4 | |
| 9X6772 | 26 STRAP-CABLE | 4 | |
| 4B0831 | 27 BOLT (5/16-18X3.75-IN) | 3 | |
| 4J4102 | 28 SPACER (0.49X0.69X3.0-IN THK) | 3 | |
| 5M2894 | 29 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 1063882 | 30 PLATE-TIMING | 1 | |
| 0S1594 | 31 BOLT (3/8-16X1-IN) | 1 | |
| 7W2479 | 32 WIRE AS-PLUG | 6 | |
| 2B8461 | 33 TERMINAL | 1 | |
| 3N1914 | 34 TERMINAL | 1 | |
| 3N1915 | 35 TERMINAL (SNAP) | 1 | |
| 5P6036 | 36 WIRE-IGNITION (.4M) | ||
| 7N2992 | 37 INSULATOR | 1 | |
| 7N2993 | 38 COVER-SPARK PLUG | 1 | |
| 0041009 | 39 FITTING | 1 | |
| 1063513 | 40 POINTER-TIMING | 1 | |
| 0L1143 | 41 BOLT (3/8-16X2.5-IN) | 2 |
