231-6378 GEAR GP-REARS/N EHX1-UP

Group No: 231-6378 · Commonality

Part Number	Part Name	Qty
4N0848	1 SLEEVE-WEAR	1
4N7183	2 RING-RETAINING	2
5B0213	3 BOLT (3/8-16X2.375-IN)	6
5F7403	4 LOCKWASHER	2
5F7404	5 LOCKNUT-BEARING	2
5P1370	6 BEARING AS-ROLLER	2
1025861	7 PLATE-THRUST	2
1851497	8 GEAR AS-IDLER (79-TEETH)	1
2249664	8A BUSHING	1
1940620	9 HOSE AS	2
2241219	10 SHAFT-STUB	1
2241220	11 PLATE	1
2241221	12 SHAFT-STUB	1
4755915	13 PLATE-SEALING	2
2249657	14 ADAPTER AS	2
4N0684	DOWEL	1
2266036	15 GEAR AS-IDLER (40/70-TEETH)	1
2266052	15A BUSHING	1
1B8705	15B KEY-WOODRUFF	1
2270159	16 SHAFT-STUB	1
2285813	17 GEAR AS-CRANKSHAFT (49-TEETH)	1
4N0684	17A DOWEL	1
2291663	18 PLATE-THRUST	1
2306202	19 GEAR AS-IDLER (70/83-TEETH)	1
2249664	19A BUSHING	1
3829114	20 ADAPTER	2
2323228	21 GEAR-HYDRAULIC PUMP DRIVE (49-TEETH)	1
2364406	22 GEAR-HYDRAULIC PUMP DRIVE (49-TEETH)	1
3316188	23 GEAR AS-CAMSHAFT (56-TEETH)	2
0315085	24 BOLT-LOCKING (1/4-20X1-IN)	6
1178801	25 SEAL-O-RING	2
1A2029	26 BOLT (3/8-16X1.125-IN)	16
1T0720	27 BOLT-12 POINT HEAD (3/8-16X1.25-IN)	12
2453804	28 BOLT (3/8-16X3.5-IN)	1
2977956	29 ELBOW (INCLUDES SCREEN FILTER)	2
5E8771	30 SEAL-O-RING	2
5P4318	31 ELBOW	2
5P8429	32 SEAL-O-RING	2
6J3913	33 BOLT-12 POINT HEAD (5/8-11X3.25-IN)	12
5024034	34 SEAL-O-RING	1
6V4589	35 SEAL-O-RING	2
2147568	36 SEAL-O-RING	2
7B3235	37 BOLT (1/2-13X1.375-IN)	8
