System And Components
475-7297 LINES GP-AIRS/N DJS1-UP
Group No: 475-7297
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P5212 | 1 HOSE | 3 | |
| 6T6158 | 2 ELBOW | 3 | |
| 5592777 | 3 HOSE | 3 | |
| 2562420 | 4 ELBOW | 1 | |
| 1227971 | 5 TUBE | 1 | |
| 1731540 | 6 BRACKET AS | 1 | |
| 1768102 | 7 CLAMP | 1 | |
| 1862002 | 8 HOSE | 3 | |
| 2540736 | 9 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3647994 | 10 TUBE | 1 | |
| 3647996 | 11 TUBE | 1 | |
| 3647997 | 12 TUBE | 1 | |
| 3647998 | 13 TUBE | 1 | |
| 4757135 | 14 BRACKET AS | 1 | |
| 4758366 | 15 BRACKET AS | 1 | |
| 4781515 | 16 TUBE AS | 1 | |
| 1255059 | 17 ELBOW | 1 | |
| 2087448 | 18 CLAMP | 12 | |
| 3E7424 | 19 CLAMP-HOSE | 14 | |
| 4L6454 | 20 BOLT (3/8-16X1-IN) | 4 | |
| 8T4121 | 21 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 5P1076 | 22 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 6V6782 | 23 CLIP (SLOT) | 3 | |
| 6V6783 | 24 CLIP (TAB) | 3 | |
| 7X7729 | 25 WASHER (11X25X3-MM THK) | 5 | |
| 8T4139 | 26 BOLT (M12X1.75X30-MM) | 2 | |
| 8T4186 | 27 BOLT (M10X1.5X40-MM) | 3 | |
| 8T4195 | 28 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4223 | 29 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T8917 | 30 BOLT (1/2-13X1.25-IN) | 1 | |
| 9B7237 | 31 BOLT (3/8-16X1.25-IN) | 1 | |
| 4757301 | 32 TUBE | 1 |
