System And Components
7N9246 FAN BELT TIGHTENER GROUPSERIAL NO. 87X160-UP
Group No: 7N9246
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8N5581 | 1 STUD | 1 | |
| 2N2280 | LOCKNUT-WASHER | 1 | |
| 8N5827 | 2 ABSORBER AS | 1 | |
| 8N5579 | 3 RETAINER | 1 | |
| 1D5117 | 4 NUT-JAM | 1 | |
| 2M2742 | 5 PLATE-RETAINER | 1 | |
| 0L1351 | 6 BOLT | 1 | |
| 5M2894 | 7 WASHER | 1 | |
| 1S8687 | 8 SPACER | 1 | |
| 8B2327 | 9 RING-RETAINER | 1 | |
| 6B1124 | 10 BALL BEARING | 2 | |
| 2S6150 | 11 COVER-PULLEY | 1 | |
| 2S6151 | GASKET | 1 | |
| 2S6160 | 12 WASHER-HARD | 1 | |
| 0S1618 | 13 BOLT | 4 | |
| 4N2697 | 14 PULLEY-TIGHTENER | 1 | |
| 5M9735 | 15 SEAL-LIP TYPE | 1 | |
| 4S7916 | 16 SPACER | 1 | |
| 6S6308 | 17 PIN | 1 | |
| 3B4617 | COTTER | 1 | |
| 4N2693 | 18 ARM AS-TIGHTENER | 1 | |
| 4S5367 | BUSHING AS | 1 | |
| 4N0955 | PIN-DOWEL | 1 | |
| 0S1591 | 19 BOLT | 4 | |
| 4N2690 | 20 SHAFT AS | 1 | |
| 1S9209 | SHAFT-TIGHTENER | 1 | |
| 4N0955 | 21 PIN-DOWEL | 1 | |
| 8T4223 | 22 WASHER | 1 | |
| 5S7379 | 23 BOLT | 1 | |
| 8T4896 | WASHER-HARD | 1 | |
| 4W5746 | KIT-BEARING | 1 |
