System And Components
1W4933 TIGHTENER GP-BELTS/N 6AB1-UP
Group No: 1W4933
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2N2280 | 1 LOCKNUT-WASHER | 1 | |
| 4L9337 | 2 BOLT | 3 | |
| 4N2697 | 3 PULLEY-TIGHTENER | 1 | |
| 4M6425 | 4 BOLT | 4 | |
| 8B2327 | 5 RING-RETAINER | 1 | |
| 1W4695 | 6 ARM AS | 1 | |
| 4N0955 | PIN-DOWEL | 1 | |
| 4S5367 | BUSHING AS | 1 | |
| 2S1511 | 7 HOSE AS | 1 | |
| 3B8485 | 8 FITTING-HYDRAULIC | 1 | |
| 6V8188 | 9 NUT | 1 | |
| 8T4223 | 10 WASHER-HARD | 1 | |
| 8N5579 | 11 RETAINER | 1 | |
| 8N5827 | 12 ABSORBER AS | 1 | |
| 5M9735 | 13 SEAL-LIP TYPE | 1 | |
| 4S7916 | 14 SPACER | 1 | |
| 6S6308 | 15 PIN | 1 | |
| 3B4617 | 16 COTTER | 1 | |
| 2M2742 | 17 PLATE-RETAINER | 1 | |
| 5S7379 | 18 BOLT | 2 | |
| 8T4896 | 19 WASHER-HARD | 2 | |
| 3B6552 | 20 ELBOW | 1 | |
| 8N5581 | 21 STUD | 1 | |
| 1W4693 | 22 SHAFT AS | 1 | |
| 4N0955 | PIN-DOWEL | 1 | |
| 1S9209 | SHAFT-TIGHTENER | 1 | |
| 7X0592 | 23 WASHER-HARD | 1 | |
| 2S6150 | 24 COVER-PULLEY | 1 | |
| 2S6151 | 25 GASKET | 1 | |
| 6B1124 | 26 BALL BEARING | 2 | |
| 1S8687 | 27 SPACER | 1 |
