System And Components
8X-4062 WIRING GP-CABS/N 4XJ1-UP; 2TK1-UP
Group No: 8X-4062
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 12 | |
| 8C9678 | 2 LAMP GP-DOME (24-VOLT) | 1 | |
| 4B1237 | 3 SCREW-MACHINE (10-32X12.7-MM) | 2 | |
| 9F5599 | 4 LOCKWASHER | 5 | |
| 3T3045 | 5 CLIP AS | 4 | |
| 9D4068 | 6 SWITCH-PUSH BUTTON (DOME LIGHT) | 1 | |
| 2A7012 | 7 HARNESS AS | 1 | |
| 5T9327 | 8 GROMMET | 1 | |
| 5T0038 | 9 BRACKET | 1 | |
| 5P8167 | 10 BOLT (3/8-16X0.625-IN) | 2 | |
| 9G4360 | 11 CAP-CONNECTOR | 1 | |
| 3E5730 | 12 FILM (DIAGNOSTIC) | 1 | |
| 4D7794 | 13 CLIP | 2 | |
| 9G9154 | 14 CLIP | 6 | |
| 5M3062 | 15 BOLT (3/8-16X0.75-IN) | 25 | |
| 8T4896 | 16 WASHER-HARD (10.2X18.5X2.5-MM THK) | 30 | |
| 3T5438 | 17 DISTRIBUTOR GP-ELECTRONIC (TRANS SPEED) | 1 | |
| 4M0061 | 18 BOLT (5/16-18X0.75-IN) | 2 | |
| 8T4224 | 19 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8M2770 | 20 CLIP (LOOP) | 4 | |
| 7X1362 | 21 CONTROL GP-ELECTRONIC (NEUTRAL START) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 5 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 7 | |
| 7N7781 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 9G3668 | HOUSING-PLUG | 1 | |
| 4M5282 | 22 BOLT (1/4-20X1.5-IN) | 2 | |
| 5P4115 | 23 WASHER-HARD (7.2X19X2-MM THK) | 4 | |
| 8X1482 | 24 WIRE AS | 1 | |
| 3T3048 | 25 CLIP AS | 7 | |
| 9M8406 | 26 CLIP (LOOP) | 1 | |
| 5V2998 | 27 PLATE | 1 | |
| 6G9462 | 28 HARNESS AS-WIRING (TURN SIGNAL) | 1 | |
| 9G9813 | 29 ALARM GP (24-VOLT) | 1 | |
| 9G9813 | 29A ALARM GP (24-VOLT) | 1 | |
| 2H1855 | 30 SWITCH AS-FOOT | 1 | |
| 6V8362 | SCREW-MACHINE (8-32X0.31-IN) | 3 | |
| 9B7233 | LOCKWASHER | 3 | |
| 8T9364 | 31 BOLT (1/4-20X0.625-IN) | 2 | |
| 8T4205 | 32 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 3T0050 | 33 CLIP | 11 | |
| 1086965 | 34 PANEL GP-CIRCUIT BREAKER | 1 | |
| 1055161 | 35 PLATE | 1 | |
| 8C9609 | 36 CONTROL GP-ELECTRONIC (GEAR INDICATOR) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 4 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 6 | |
| 7N8205 | HOUSING-PLUG | 1 | |
| 7T7370 | SEAL-SECURITY | 2 | |
| 9G3670 | HOUSING-PLUG | 1 | |
| 9G3695 | PLUG-SEAL | 1 | |
| 4M5281 | 37 BOLT (1/4-20X0.75-IN) | 6 | |
| 9G9150 | 38 CLIP | 4 | |
| 9G5589 | 39 SWITCH AS (TURN SIGNAL) | 1 | |
| 5L7200 | SCREW (8-32X0.375-IN) | 1 | |
| 9B7233 | LOCKWASHER | 1 | |
| 8D7712 | 40 FASTENER | 3 | |
| 9F8125 | 41 LOCKWASHER | 3 | |
| 8W2066 | 42 LEVER-TURN SIGNAL | 1 | |
| 1W3306 | 43 GAUGE GP-AIR PRESSURE | 1 | |
| 7N5876 | 44 LAMP (24-VOLT, 0.2-AMPERE) | 1 | |
| 7K1181 | 45 STRAP-CABLE | 1 | |
| 3E5184 | 46 CONTROL GP-SECONDARY STEERING | 1 | |
| 1082232 | 47 HARNESS AS-CAB | 1 | |
| 3P3839 | 48 GROMMET | 1 | |
| 6D2667 | 49 CLIP | 1 | |
| 3T0376 | 50 SWITCH AS-MAGNETIC (POWER RELAY) | 1 | |
| 4F2294 | NUT-JAM (5/16-24-THD) | 2 | |
| 6V8378 | NUT (10-32-THD) | 2 | |
| 9X2042 | 51 SCREW-TRUSS HEAD (M6X1X12-MM) | 8 | |
| 5P0537 | 52 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 1262343 | 53 HARNESS AS-CAB | 1 | |
| 2S9255 | 54 BOLT-SOCKET HEAD (4-40X0.375-IN) | 4 | |
| 5S4246 | 55 LOCKWASHER | 4 | |
| 6B4540 | 56 NUT (4-40-THD) | 4 | |
| 1S0994 | 57 CLIP (LOOP) | 3 | |
| 3E2035 | 58 SWITCH AS-PRESSURE (RETARDER) | 1 | |
| 7N9738 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 6D1126 | 59 WIRE AS | 1 | |
| 5P8523 | 60 GROMMET | 1 | |
| 8D6946 | 61 FLASHER AS (24-VOLT) | 1 | |
| 1086564 | 62 HARNESS AS | 1 | |
| 3E7279 | 63 SWITCH GP-MAGNETIC (24-VOLT)(BRAKE) | 1 | |
| 5S7379 | 64 BOLT (3/8-16X0.875-IN) | 3 | |
| 9G9152 | 65 CLIP | 4 | |
| 5P6264 | 66 GROMMET | 1 | |
| 9W1494 | 67 KIT-SERVICE METER (24-VOLT) | 1 | |
| 4B2049 | 68 NUT (10-32-THD) | 2 | |
| 2A7017 | 69 HARNESS AS-TRANSMISSION | 1 | |
| 2M9346 | 70 SWITCH AS-PRESSURE (STOP LIGHT) | 1 | |
| 6V8378 | NUT (10-32-THD) | 2 | |
| 8F1434 | LOCKWASHER | 2 | |
| 3E2034 | 71 SWITCH AS-PRESSURE (SERV/RETR BRAKE) | 1 | |
| 7N9738 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 3T3047 | 72 CLIP AS | 4 | |
| 5P2369 | 73 CLIP (LOOP) | 1 | |
| 8T9792 | 74 SWITCH AS-PRESSURE (AIR BRAKE) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 2 | |
| 7N7781 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 9M4972 | 75 CLIP (LOOP) | 3 | |
| 4D7388 | 76 CLIP | 1 | |
| 4S1962 | 77 CLIP (LOOP) | 5 | |
| 7D7233 | 78 CLIP (LOOP) | 2 | |
| 5L4507 | 79 SCREW-MACHINE (10-32X0.875-IN) | 3 | |
| 3E9758 | 80 FILM-OVERHEAD | 1 | |
| 8X8047 | 81 PLATE | 1 | |
| 8C9685 | 82 SWITCH GP-ROCKER (THROTTLE OVERRIDE) | 1 | |
| 7N8419 | 83 TERMINAL-BLADE | 5 | |
| 6T6329 | 84 BEZEL | 2 | |
| 6V8927 | 85 BOLT-SOCKET HEAD (6-32X0.5-IN) | 4 | |
| 6T3990 | 86 SWITCH AS-ROCKER (FUEL INJ DISABLE) | 1 | |
| 3L8187 | LOCKWASHER | 2 | |
| 6V8374 | SCREW-MACHINE (6-32X0.25-IN) | 2 | |
| 3T3046 | 87 CLIP AS | 4 | |
| 2A7013 | 88 HARNESS AS | 1 | |
| 8C6354 | 89 CAP-RECEPTACLE (ET CONNECTOR) | 1 | |
| 8T9405 | 90 BOLT-SOCKET HEAD (M4X0.7X16-MM) | 4 | |
| 8C9660 | 91 WASHER (4.6X7.9X0.8-MM THK) | 4 | |
| 5C8312 | 92 NUT (M4X0.7-THD) | 4 | |
| 8X8066 | 93 PLATE | 1 | |
| 3E5239 | 94 RELAY AS (24-VOLT)(STOP LAMP) | 1 | |
| 6V2687 | 95 SCREW-PAN HEAD (10-24X1-IN) | 1 | |
| 4B4274 | 96 WASHER (5.5X13X1.2-MM THK) | 1 | |
| 6V0292 | 97 PLUG | 1 | |
| 1H3338 | 100 LOCKWASHER | 2 | |
| 9D3721 | 101 SWITCH-TOGGLE (SINGLE POLE)(SERV SET) | 1 | |
| 9D3721 | 101A SWITCH-TOGGLE (SINGLE POLE)(SERV CLEAR) | 1 | |
| 2A7073 | 102 HARNESS AS-CAB | 1 | |
| 3E2033 | 103 SWITCH AS-PRESSURE (PARKING BRAKE) | 1 | |
| 3E2033 | 103A SWITCH AS-PRESSURE (SECONDARY BRAKE) | 1 | |
| 7N9738 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 8T7964 | 104 NUT (M6X1-THD) | 2 |
