System And Components
1W-5255 MUFFLER GPS/N 5RK1-UP
Group No: 1W-5255
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8N4401 | 1 CLAMP-V BAND | 2 | |
| 4W0222 | 2 ELBOW AS | 1 | |
| 2W9766 | 3 RING-SEAL | 2 | |
| 4W0221 | 4 PIPE AS | 2 | |
| 2W8851 | 5 RING-SEAL | 2 | |
| 4W0223 | 6 ELBOW AS | 1 | |
| 2W9067 | 7 SLEEVE AS | 1 | |
| 5S7382 | 8 BOLT (3/8-16X1.375-IN) | 4 | |
| 8T4896 | 9 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 5S7379 | 10 BOLT (3/8-16X0.875-IN) | 18 | |
| 5T6432 | 11 ELBOW | 1 | |
| 5T7938 | 12 TUBE AS | 1 | |
| 2W3773 | 13 MUFFLER AS | 1 | |
| 4N9330 | 14 CLAMP | 2 | |
| 5P2424 | 15 BOLT (1/2-13X2.25-IN) | 3 | |
| 1K6872 | 16 LOCKNUT (1/2-13-THD) | 7 | |
| 8T4223 | 17 WASHER-HARD (13.5X25.5X3-MM THK) | 10 | |
| 5T6928 | 18 STRAP AS | 4 | |
| 5S7383 | 19 BOLT (3/8-16X1.75-IN) | 8 | |
| 2K4973 | 20 LOCKNUT (3/8-16-THD) | 8 | |
| 5T6927 | 21 BRACKET AS | 2 | |
| 5P1075 | 22 WASHER-HARD (10.2X22.5X3-MM THK) | 16 | |
| 5T6978 | 23 PLATE | 1 | |
| 4W0224 | 24 ELBOW AS | 1 | |
| 4W0225 | 25 ELBOW AS | 1 | |
| 1W4161 | 26 CLAMP | 1 | |
| 2W6737 | 27 MUFFLER AS | 1 | |
| 5T4278 | 28 STRAP AS | 2 | |
| 1W1305 | 29 CLAMP | 1 | |
| 8W4381 | 30 PIPE-EXTENSION | 1 | |
| 8W4382 | 31 PIPE-EXTENSION | 1 |
