System And Components
2A-6506 WIRING GP-CAB -EMSS/N 1HL195-405
Group No: 2A-6506
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8M2770 | 1 CLIP (LOOP) | 1 | |
| 5M3062 | 2 BOLT (3/8-16X0.75-IN) | 3 | |
| 8T4896 | 3 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 9G8009 | 4 SWITCH AS-PRESSURE (BRAKE AIR) | 1 | |
| 6V8376 | SCREW-MACHINE (8-32X0.25-IN) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 7X6398 | 5 LAMP GP-DOME (CAB) | 1 | |
| 9F8125 | LOCKWASHER | 3 | |
| 4B1238 | SCREW-MACHINE (10-32X15.88-MM) | 3 | |
| 3T3048 | 6 CLIP AS | 1 | |
| 7N9737 | 7 HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 9G3695 | PLUG-SEAL | 1 | |
| 3S2093 | 8 STRAP-CABLE | 4 | |
| 2A6491 | 9 PANEL GP-CIRCUIT BREAKER (EMS) | 1 | |
| 9X2042 | 10 SCREW-TRUSS HEAD (M6X1X12-MM) | 4 | |
| 9G4360 | 11 CAP-CONNECTOR | 1 | |
| 6I1653 | 12 BRACKET AS | 1 | |
| 6D2392 | SHIM (.060 IN THK) | 1 | |
| 6V5048 | SEAL-O-RING | 2 | |
| 6V1926 | SENSOR GP-PRESSURE (ATMOSPHERIC) | 1 | |
| 9X0262 | ADAPTER | 1 | |
| 2G1136 | 13 GROMMET | 1 | |
| 3T3047 | 14 CLIP AS | 2 | |
| 3S8665 | 15 CLIP (LOOP) | 2 | |
| 1080358 | 16 FLASHER AS (24-VOLT) | 1 | |
| 4B1237 | SCREW-MACHINE (10-32X12.7-MM) | 2 | |
| 9F8125 | LOCKWASHER | 2 | |
| 5P4115 | 17 WASHER-HARD (7.2X19X2-MM THK) | 2 | |
| 8T4224 | 18 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 2H1855 | 19 SWITCH AS-FOOT (HEAD LIGHTS) | 1 | |
| 6V8362 | SCREW-MACHINE (8-32X0.31-IN) | 3 | |
| 9B7233 | LOCKWASHER | 3 | |
| 4B1320 | SCREW-MACHINE (1/4-20X0.625-IN) | 2 | |
| 3T3046 | 20 CLIP AS | 1 | |
| 8T4205 | 21 WASHER-HARD (7.2X14.5X2-MM THK) | 13 | |
| 8C9609 | 22 CONTROL GP-ELECTRONIC (GEAR INDICATOR) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 4 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 6 | |
| 7N8205 | HOUSING-PLUG | 1 | |
| 7T7370 | SEAL-SECURITY | 2 | |
| 8C9976 | FILM-DISPLAY (GEAR INDICATOR) | 1 | |
| 9G3670 | HOUSING-PLUG | 1 | |
| 5T8563 | 23 PANEL AS | 1 | |
| 9G9152 | 24 CLIP | 2 | |
| 7N8419 | 25 TERMINAL-BLADE | 3 | |
| 6T3991 | SWITCH AS-ROCKER (BACK-UP LIGHTS) | 1 | |
| 3L8187 | LOCKWASHER | 3 | |
| 6V8374 | SCREW-MACHINE (6-32X0.25-IN) | 3 | |
| 6T6329 | BEZEL | 1 | |
| 6V8927 | BOLT-SOCKET HEAD (6-32X0.5-IN) | 2 | |
| 5P5824 | 26 HOLDER | 1 | |
| 5P5454 | ASHTRAY | 1 | |
| 8T9043 | 27 BOLT (5/16-18X0.875-IN) | 2 | |
| 5V2998 | 28 PLATE | 1 | |
| 9D4068 | 29 SWITCH-PUSH BUTTON (DOME LIGHT) | 1 | |
| 7N5876 | 30 LAMP (24-VOLT, 0.2-AMPERE)(OVERHEAD CONSOLE) | 2 | |
| 3T3437 | 31 RESISTOR AS-DIMMER | 1 | |
| 3T3270 | WIRE AS (16-GA) | 1 | |
| 3T3272 | CLIP | 1 | |
| 5P6008 | TUBE-HEAT SHRINK (6.35-MM DIA)(10 CM) | ||
| 9G9154 | 32 CLIP | 1 | |
| 5S7349 | 33 BOLT (1/4-20X0.5-IN) | 1 | |
| 3T0050 | 34 CLIP | 2 | |
| 5P5644 | 35 TRIM | ||
| 3T3045 | 36 CLIP AS | 1 | |
| 9M4972 | 37 CLIP (LOOP) | 1 | |
| 7X1362 | 38 CONTROL GP-ELECTRONIC (NEUTRAL START) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 5 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 7 | |
| 7N7781 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 9G3668 | HOUSING-PLUG | 1 | |
| 7X0265 | BOLT (1/4-20X2.75-IN) | 4 | |
| 6V8185 | NUT (1/4-20-THD) | 4 | |
| 4M5281 | 39 BOLT (1/4-20X0.75-IN) | 4 | |
| 9X7823 | 40 CONTROL GP-ELECTRONIC (STEERING WARNING) | 1 | |
| 9G5127 | 41 BREATHER (ATMOSPHERIC AIR)(ATMOSPHERIC PRESSURE) | 1 | |
| 5T4434 | 42 VALVE AS-SOLENOID (AUTO LUBE) | 1 | |
| 5D5569 | CONNECTOR | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N9737 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 7T3823 | 43 CONTROL GP-ELECTRONIC (AUTO LUBE) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 2 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N7782 | HOUSING-PLUG (14-GA TO 18-GA) | 1 | |
| 1146658 | 44 WASHER (6.5X17X1-MM THK) | 4 | |
| 3T3048 | 45 CLIP AS | 7 | |
| 5M3062 | 46 BOLT (3/8-16X0.75-IN) | 18 | |
| 8T4896 | 47 WASHER-HARD (10.2X18.5X2.5-MM THK) | 26 | |
| 3T3047 | 48 CLIP AS | 2 | |
| 9G9152 | 49 CLIP | 2 | |
| 3T0050 | 50 CLIP | 4 | |
| 9G9154 | 51 CLIP | 1 | |
| 8T4205 | 52 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 3T0376 | 53 SWITCH AS-MAGNETIC (MAIN RELAY) | 1 | |
| 3T0376 | 54 SWITCH AS-MAGNETIC (BACK-UP RELAY) | 1 | |
| 6V8378 | 55 NUT (10-32-THD) | 2 | |
| 4F2294 | 56 NUT-JAM (5/16-24-THD) | 2 | |
| 6V8186 | NUT-FULL (5/16-24-THD) | 2 | |
| 4L6454 | 57 BOLT (3/8-16X1-IN) | 2 | |
| 9M8406 | 58 CLIP (LOOP) | 5 | |
| 5P6264 | 59 GROMMET | 2 | |
| 8W0639 | 60 HARNESS AS (CAB, OVERHEAD CONSOLE) | 1 | |
| 3T4411 | 61 LAMP GP-FLOOD (24-VOLT)(LADDER ACCESS) | 1 | |
| 6V8188 | NUT (1/2-13-THD) | 1 | |
| 8T4223 | WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 5P8440 | 62 GROMMET | 1 | |
| 3S8664 | 63 CLIP | 2 | |
| 1142063 | 64 HARNESS AS (TRANSMISSION-CAB) | 1 | |
| 5S7379 | 65 BOLT (3/8-16X0.875-IN) | 5 | |
| 3E2034 | 66 SWITCH AS-PRESSURE (SERVICE BRAKE RETARDER) | 1 | |
| 3E2034 | 67 SWITCH AS-PRESSURE (AETA) | 1 | |
| 6V8376 | SCREW-MACHINE (8-32X0.25-IN) | 2 | |
| 1175310 | 68 HARNESS AS (MAIN CAB) | 1 | |
| 8M2770 | 69 CLIP (LOOP) | 1 | |
| 3E2033 | 70 SWITCH AS-PRESSURE (SECONDARY BRAKE) | 1 | |
| 3E2033 | 71 SWITCH AS-PRESSURE (PARKING BRAKE) | 1 | |
| 9D3721 | 72 SWITCH-TOGGLE (SINGLE POLE)(SERVICE SET/CLEAR) | 2 | |
| 3T3046 | 73 CLIP AS | 2 | |
| 9G9150 | 74 CLIP | 1 | |
| 9M4972 | 75 CLIP (LOOP) | 2 | |
| 7D4092 | 76 CLIP | 1 | |
| 3S2093 | 77 STRAP-CABLE | 7 | |
| 8C6354 | 78 CAP-RECEPTACLE (ET CONNECTOR) | 1 | |
| 6D3033 | SCREW-SOCKET HEAD (4-40X0.5-IN) | 4 | |
| 6V9497 | WASHER-HARD (3.2X6X0.5-MM THK) | 4 | |
| 6B4540 | NUT (4-40-THD) | 4 | |
| 3T0529 | 79 CONTROL GP-ELECTRONIC (AETA) | 1 | |
| 3T1265 | FILM-IDENTIFICATION (AETA) | 1 | |
| 3E7840 | CONTROL GP-ELECTRONIC (AETA) | 1 | |
| 1137849 | 80 HARNESS AS-CAB (AETA) | 1 | |
| 2M9346 | 81 SWITCH AS-PRESSURE (STOP LAMP) | 1 | |
| 6V8378 | NUT (10-32-THD) | 2 | |
| 8F1434 | LOCKWASHER | 2 | |
| 4D7794 | 82 CLIP | 1 | |
| 5P8394 | 83 SCREW-MACHINE (8-32X0.75-IN) | 4 | |
| 4B2043 | NUT (8-32-THD) | 4 | |
| 4B4863 | WASHER (4.7X11X1.2-MM THK) | 4 | |
| 8X9638 | 84 PLATE | 1 | |
| 4M5281 | 85 BOLT (1/4-20X0.75-IN) | 4 | |
| 9G6981 | 86 CONVERTER AS-ELECTRICAL (5-AMPERE)(24/12 VOLT) | 1 | |
| 1S9593 | STRAP-CABLE | 4 | |
| 3L8187 | LOCKWASHER | 5 | |
| 3T1794 | WIRE AS | 1 | |
| 3T3045 | CLIP AS | 1 | |
| 5S7349 | 87 BOLT (1/4-20X0.5-IN) | 1 | |
| 8M2770 | 88 CLIP (LOOP) | 6 | |
| 5M3062 | 89 BOLT (3/8-16X0.75-IN) | 12 | |
| 8T4896 | 90 WASHER-HARD (10.2X18.5X2.5-MM THK) | 13 | |
| 3T3048 | 91 CLIP AS | 2 | |
| 1S0994 | 92 CLIP (LOOP) | 1 | |
| 9G9154 | 93 CLIP | 3 | |
| 5S7349 | 94 BOLT (1/4-20X0.5-IN) | 5 | |
| 3T0050 | 95 CLIP | 1 | |
| 4S4455 | 96 CLIP | 1 | |
| 3S8664 | 97 CLIP | 2 | |
| 8T4205 | 98 WASHER-HARD (7.2X14.5X2-MM THK) | 5 | |
| 3S2093 | 99 STRAP-CABLE | 5 | |
| 5P8167 | 100 BOLT (3/8-16X0.625-IN) | 1 | |
| 9G9813 | 101 ALARM GP (24-VOLT)(ACTION)(OVERSPEED) | 2 | |
| 9G9150 | 102 CLIP | 2 | |
| 9G5589 | 103 SWITCH AS | 1 | |
| 5L7200 | SCREW (8-32X0.375-IN) | 1 | |
| 9B7233 | LOCKWASHER | 1 | |
| 8D7712 | 104 FASTENER | 3 | |
| 9F8125 | LOCKWASHER | 3 | |
| 8W2066 | 105 LEVER-TURN SIGNAL | 1 | |
| 3E2035 | 106 SWITCH AS-PRESSURE (RETARDER LAMP) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N9738 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 3B6768 | 107 BUSHING-REDUCER | 1 | |
| 6G9462 | 108 HARNESS AS-WIRING (TURN SIGNAL) | 1 | |
| 9M4972 | 109 CLIP (LOOP) | 1 | |
| 1V6688 | 110 GROMMET | 1 | |
| 4V5091 | 111 GROMMET | 1 | |
| 7D7233 | 112 CLIP (LOOP) | 1 | |
| 4K8864 | 113 CLIP (LOOP) | 2 | |
| 7N9738 | 114 HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 9G3695 | 115 PLUG-SEAL | 2 | |
| 9G9150 | 116 CLIP | 2 | |
| 8M2770 | 117 CLIP (LOOP) | 1 | |
| 5M3062 | 118 BOLT (3/8-16X0.75-IN) | 3 | |
| 8T4896 | 119 WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 8T4205 | 120 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 7N8419 | 121 TERMINAL-BLADE | 22 | |
| 9X2042 | 122 SCREW-TRUSS HEAD (M6X1X12-MM) | 6 | |
| 9G9154 | 123 CLIP | 1 | |
| 7N5876 | 124 LAMP (24-VOLT, 0.2-AMPERE)(BRAKE AIR INDICATOR) | 1 | |
| 9G9287 | 125 CONTROL GP-ENGINE ELECTRONIC (ENGINE SHUTDOWN) | 1 | |
| 1S9593 | STRAP-CABLE | 3 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 2 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 4 | |
| 9G3670 | HOUSING-PLUG | 1 | |
| 9G3695 | PLUG-SEAL | 1 | |
| 5S7349 | 126 BOLT (1/4-20X0.5-IN) | 2 | |
| 4D1836 | 127 SWITCH-TOGGLE (AETA TEST) | 1 | |
| 3S2093 | 128 STRAP-CABLE | 1 | |
| 3T5438 | 129 DISTRIBUTOR GP-ELECTRONIC (TRANSMISSION SPEED) | 1 | |
| 4M0061 | 130 BOLT (5/16-18X0.75-IN) | 2 | |
| 8T4224 | WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 5T9148 | 131 BRACKET | 1 | |
| 9W0335 | 132 LIGHTER AS-CIGAR (24-VOLT) | 1 | |
| 9D3721 | 133 SWITCH-TOGGLE (SINGLE POLE)(BRAKE RETRACT) | 1 | |
| 9G2264 | 134 CLIP-CONNECTOR | 1 | |
| 9W1495 | 135 KIT-SERVICE METER | 1 | |
| 8T0701 | FILM-SERVICE METER | 1 | |
| 9W1411 | WIRE AS | 1 | |
| 6T6969 | 136 GUARD-SWITCH | 2 | |
| 1W3306 | 137 GAUGE GP-AIR PRESSURE (BRAKE AIR) | 1 | |
| 9G7641 | 138 SWITCH GP-START (ENGINE, KEY)(ENGINE)(KEY) | 1 | |
| 7T1874 | TERMINAL-BLADE | 2 | |
| 8C9812 | 139 SWITCH AS-TOGGLE (STARTING AID) | 1 | |
| 3L8187 | LOCKWASHER | 3 | |
| 6T3631 | NUT-HEX (15/32-32-THD) | 2 | |
| 6T3632 | LOCKWASHER | 1 | |
| 6T3633 | RING-LOCKING | 1 | |
| 6V8374 | SCREW-MACHINE (6-32X0.25-IN) | 3 | |
| 3E9465 | 140 FILM-INSTRUCTION (CONSOLE) | 1 | |
| 0100742 | 141 SCREW-MACHINE (6-32X1-IN) | 2 | |
| 6K3274 | PLATE-RIVET | 2 | |
| 9B1117 | LOCKWASHER | 2 | |
| 4B2041 | NUT (6-32-THD) | 2 | |
| 6G4195 | 142 SWITCH AS-LIMIT (BACK-UP ALARM) | 1 | |
| 3L8187 | LOCKWASHER | 3 | |
| 6V8373 | SCREW-MACHINE (6-32X0.187-IN) | 3 | |
| 6T3990 | 143 SWITCH AS-ROCKER (INTERIOR LIGHT) | 1 | |
| 3L8187 | LOCKWASHER | 2 | |
| 6V8374 | SCREW-MACHINE (6-32X0.25-IN) | 2 | |
| 6T6329 | 144 BEZEL | 5 | |
| 6T3991 | 145 SWITCH AS-ROCKER (PANEL LIGHTS) | 1 | |
| 6T3991 | 146 SWITCH AS-ROCKER (LADDER ACCESS LIGHTS) | 1 | |
| 3L8187 | LOCKWASHER | 3 | |
| 6V8374 | SCREW-MACHINE (6-32X0.25-IN) | 3 | |
| 8T2966 | 147 FILM-INSTRUMENT PANEL | 1 | |
| 6T3989 | 148 SWITCH AS-ROCKER (FOG LIGHTS) | 1 | |
| 6T3989 | 149 SWITCH AS-ROCKER (HEAD LIGHTS) | 1 | |
| 3L8187 | LOCKWASHER | 8 | |
| 6V8374 | SCREW-MACHINE (6-32X0.25-IN) | 8 | |
| 6V8927 | 150 BOLT-SOCKET HEAD (6-32X0.5-IN) | 10 | |
| 1146658 | 151 WASHER (6.5X17X1-MM THK) | 6 |
