2A-6529 BATTERY & WIRING GP -CHASSIS/EMSS/N 7EK371-UP

Group No: 2A-6529
Part NumberPart NameQty
5S73791 BOLT (3/8-16X0.875-IN)27
8T48962 WASHER-HARD (10.2X18.5X2.5-MM THK)54
5P92993 CLIP (LOOP)7
5M30624 BOLT (3/8-16X0.75-IN)27
5P92975 CLIP (LOOP)1
5T94146 HARNESS AS (TURN SIGNAL, RH)1
3T39677 LAMP GP-SIGNAL (PARKING, TURN)(AMBER)4
7S43468 SCREW-MACHINE (10-32X0.5-IN)12
9F5599LOCKWASHER24
4B2049NUT (10-32-THD)12
11758839 CABLE AS1
1584610TERMINAL AS (NEGATIVE)1
7X1591TERMINAL AS (POSITIVE)1
1M6119BOLT (5/16-18X1.375-IN)2
1M6120NUT (5/16-18-THD)2
7N5274COVER AS-TERMINAL (BLACK)1
8C3056CABLE (2-GA, RED)(30CM)
8N1725COVER AS-TERMINAL (RED)1
116716010 CABLE AS-BATTERY1
1M6119BOLT (5/16-18X1.375-IN)1
1M6120NUT (5/16-18-THD)1
7N5274COVER AS-TERMINAL (BLACK)1
8C0596CABLE (2-GA)(725CM)
0375197BOOT1
0918404TERMINAL-RING (2-GA, 3/8-IN SCREW)1
1584610TERMINAL AS (NEGATIVE)1
5K329411 CLIP1
5P150612 HOSE (162CM)
117526713 HARNESS AS (BATTERY CABLE)1
9G915014 CLIP7
4S445615 CLIP9
7D409216 CLIP11
5P150617 HOSE (168CM)
4D779418 CLIP11
4L645419 BOLT (3/8-16X1-IN)2
5P107520 WASHER-HARD (10.2X22.5X3-MM THK)10
3D785421 SPACER (ROUND)1
6D2256SPACER (SQUARE)1
6V818822 NUT (1/2-13-THD)1
6N798923 LAMP GP-FLOOD (RH ENGINE LAMP)1
5P908524 CLIP (LOOP)4
8W268625 BRACKET1
3J481826 LOCKWASHER1
4D132627 LOCKWASHER2
7I461828 HARNESS AS (LADDER, LH)1
3S866529 CLIP (LOOP)2
3T304630 CLIP AS2
5T941331 HARNESS AS (TURN SIGNAL)(LH)1
3J190732 SEAL-O-RING1
3E6461SWITCH AS-PRESSURE (STEERING PUMP OIL)(HIGH)1
5P0562LOCKWIRE1
3J7354SEAL-O-RING1
5P9617ADAPTER1
033824833 CLIP (LOOP)4
9M499534 CLIP2
6D463635 CLIP (LOOP)3
7K118136 STRAP-CABLE8
3M721237 TERMINAL-BATTERY1
5M306238 BOLT (3/8-16X0.75-IN)11
8T489639 WASHER-HARD (10.2X18.5X2.5-MM THK)30
4D779440 CLIP2
130760641 HARNESS AS (CHASSIS)1
4S445642 CLIP2
5S737943 BOLT (3/8-16X0.875-IN)16
8N384444 SENDER-TEMPERATURE (SERVICE BRAKE OIL)1
3K036045 SEAL-O-RING1
7N7854SWITCH AS-TEMPERATURE (BRAKE OIL)1
6V8376SCREW-MACHINE (8-32X0.25-IN)2
9B7233LOCKWASHER2
5P602946 LOCKWIRE
124294347 HARNESS AS-TRANSMISSION (CHASSIS)1
9M840648 CLIP (LOOP)13
3S866549 CLIP (LOOP)4
8W1087TUBE2
033824850 CLIP (LOOP)1
130693151 HARNESS AS (REAR LIGHTS)1
8M277052 CLIP (LOOP)7
7N371853 CLIP2
6D283454 CLIP1
3J190755 SEAL-O-RING2
3E780956 SWITCH AS-PRESSURE (STEERING PUMP OIL)(LOW)1
2T301957 CLIP (LOOP)2
5K845158 CLIP (LOOP)2
7K118159 STRAP-CABLE16
130731460 HARNESS AS-SENSOR (AETA, DIFFERENTIAL OIL FILTER)1
130731361 HARNESS AS-CHASSIS (AETA, DIFFERENTIAL OIL FILTER)1
3S209362 STRAP-CABLE4
4D154463 CLIP4
4D812364 CLIP (LOOP)1
115307165 CLIP AS-CONNECTING (6-PIN)1
1153072CLIP AS-CONNECTING (8-PIN)1
4L645466 BOLT (3/8-16X1-IN)3
5K329467 CLIP2
4S445568 CLIP2
8W268669 BRACKET1
9G915070 CLIP2
5M306271 BOLT (3/8-16X0.75-IN)27
8T489672 WASHER-HARD (10.2X18.5X2.5-MM THK)47
4D779473 CLIP4
6N798974 LAMP GP-FLOOD (LH ENGINE LAMP)1
3D785475 SPACER (ROUND)1
6D2256SPACER (SQUARE)1
3J481876 LOCKWASHER2
6V8188NUT (1/2-13-THD)2
5P816777 BOLT (3/8-16X0.625-IN)9
8M277078 CLIP (LOOP)12
8K143379 GROMMET4
7V6063BOLT AS16
7I4628BRACKET AS4
9X716680 LAMP GP-HEAD (HIGH BEAM)2
9B723781 BOLT (3/8-16X1.25-IN)1
6D424682 CLIP (LOOP)10
2R050483 NUT (5/16-18-THD)8
8T8911BOLT (5/16-18X2-IN)8
7D164984 WASHER-HARD (13.5X32X5-MM THK)2
3T4411LAMP GP-FLOOD (24-VOLT)(LADDER ACCESS)1
9G369585 PLUG-SEAL1
7N9737HOUSING-RECEPTACLE (14-GA TO 18-GA)1
8E155086 BRACKET AS8
9F2978NUT-WELD (3/8-16-THD)2
7I538287 HARNESS AS2
9X716588 LAMP GP-HEAD (24-VOLT, LOW BEAM)6
7I461989 HARNESS AS (HEADLIGHTS)1
3K036090 SEAL-O-RING2
9X778191 SWITCH GP-BYPASS (TRANSMISSION OIL FILTER)1
6T440992 GUARD AS1
4D812393 CLIP (LOOP)2
9M499594 CLIP1
3S209395 STRAP-CABLE6
3E695596 SENSOR GP-SPEED (TC OUTPUT)1
5S737997 BOLT (3/8-16X0.875-IN)10
5P908598 CLIP (LOOP)2
7N371899 CLIP2
1169933100 SWITCH AS-PRESSURE (TC INLET FILTER)1
3E3361PLUG AS-CONNECTOR (2-PIN)1
8T8729PIN-CONNECTOR (16-GA TO 20-GA)2
9X1813SLEEVE
5P6029101 LOCKWIRE
9G3341102 SWITCH AS-TEMPERATURE (TRANSMISSION FILTER ARM)1
6V8376SCREW-MACHINE (8-32X0.25-IN)2
9B7233LOCKWASHER2
4D1326103 LOCKWASHER2
1081289104 LAMP GP-SIGNAL (STOP, TAIL)(RED)2
3S8665105 CLIP (LOOP)2
1236449106 ALARM GP (BACK UP)1
3E3365WEDGE-RECEPTACLE LOCK (2-PIN)1
5P5677WIRE (18-GA, BLACK)
8T8729PIN-CONNECTOR (16-GA TO 20-GA)2
8T9379107 BOLT (3/8-16X4.25-IN)2
6V8801108 NUT (3/8-16-THD)2
5P1075109 WASHER-HARD (10.2X22.5X3-MM THK)1
8T4223110 WASHER-HARD (13.5X25.5X3-MM THK)2
1167156111 CABLE AS1
8C0596CABLE (2-GA)(725CM)
0375197BOOT2
0918404TERMINAL-RING (2-GA, 3/8-IN SCREW)2
9G9154112 CLIP1
3T3045113 CLIP AS4
7I5124114 HARNESS AS-FRONT LIGHTING2
4S4455115 CLIP1
6V8188116 NUT (1/2-13-THD)2
9G9152117 CLIP1
1182856118 PLATE1
8T4896119 WASHER-HARD (10.2X18.5X2.5-MM THK)3
5M3062BOLT (3/8-16X0.75-IN)3
8M2770120 CLIP (LOOP)1
4D9517121 CLIP1
8T4223WASHER-HARD (13.5X25.5X3-MM THK)1
8T9383BOLT (1/2-13X0.75-IN)1
7I4821122 HARNESS AS (ENGINE SHUTDOWN)(ENGINE SHUTDOWN)1
7N3718123 CLIP3
5P8167124 BOLT (3/8-16X0.625-IN)1
5P1075WASHER-HARD (10.2X22.5X3-MM THK)1
1167156125 CABLE AS1
8C0596CABLE (2-GA)(725CM)
0375197BOOT2
0918404TERMINAL-RING (2-GA, 3/8-IN SCREW)2
3S2093126 STRAP-CABLE2
7N7854127 SWITCH AS-TEMPERATURE (TC OIL)1
6V8376SCREW-MACHINE (8-32X0.25-IN)2
9B7233LOCKWASHER2
3K0360SEAL-O-RING1
6B4540128 NUT (4-40-THD)4
6D3033SCREW-SOCKET HEAD (4-40X0.5-IN)4
6V9497WASHER-HARD (3.2X6X0.5-MM THK)4
7N0718129 SWITCH GP-DISCONNECT1
3E5169130 GUARD-SWITCH1
8D9537131 CAP-DUST1
8D2676132 SWITCH AS-TOGGLE (SINGLE POLE)(ENGINE FLOOD LAMP)1
3L8187LOCKWASHER2
6T3631NUT-HEX (15/32-32-THD)2
6T3632LOCKWASHER1
6T3633RING-LOCKING1
6V8374SCREW-MACHINE (6-32X0.25-IN)2
2A7321133 BOX AS1
8F8551HINGE-BUTT1
4D1836134 SWITCH-TOGGLE (LADDER ACCESS LAMP)1
4D1836135 SWITCH-TOGGLE (ENGINE SHUTDOWN)1
9X4381136 LAMP GP-FLOOD (24-VOLT)(BACK UP)2
6V1119137 LAMP GP-SIGNAL (24-VOLT)(AMBER)2
8T4133138 NUT (M10X1.5-THD)4
8T4121WASHER-HARD (11X21X2.5-MM THK)4
6V8188139 NUT (1/2-13-THD)8
8T4223140 WASHER-HARD (13.5X25.5X3-MM THK)4
9D6635141 HOLD-DOWN AS-BATTERY2
4D8951142 ROD4
3T5760143 BATTERY GP (12-VOLT, 750-CCA)2
7N7849144 SWITCH AS-TEMPERATURE (AFTERCOOLER)1
6V8376SCREW-MACHINE (8-32X0.25-IN)2
9B7233LOCKWASHER2
8T4171145 BOLT (M6X1X12-MM)2
9X8256WASHER (6.6X12X2-MM THK)2
2V3216146 CLIP (LOOP)1
3E5239147 RELAY AS (24-VOLT)1
9X9584148 RESISTOR AS2
3S2093149 STRAP-CABLE16
8T9043150 BOLT (5/16-18X0.875-IN)2
8T4224151 WASHER-HARD (8.8X16X2-MM THK)6
9X3207152 TIMER GP1
9G9150153 CLIP3
8T4191154 BOLT (M10X1.5X16-MM)2
8T4121155 WASHER-HARD (11X21X2.5-MM THK)3
8T4896156 WASHER-HARD (10.2X18.5X2.5-MM THK)19
6V8801157 NUT (3/8-16-THD)2
9M8406158 CLIP (LOOP)2
4L6454159 BOLT (3/8-16X1-IN)3
5P6029160 LOCKWIRE
9G9152161 CLIP3
8T4136162 BOLT (M10X1.5X25-MM)1
5S7379163 BOLT (3/8-16X0.875-IN)8
9G9154164 CLIP3
3T3048165 CLIP AS3
5M3062166 BOLT (3/8-16X0.75-IN)9
4M7146167 STRAP AS-GROUND1
3S2093168 STRAP-CABLE10
4V4760169 COVER1
6V8189170 NUT (5/16-18-THD)1
4M0061171 BOLT (5/16-18X0.75-IN)1
4D7794172 CLIP3
8T8911173 BOLT (5/16-18X2-IN)2
3V6909174 BLOCK1
3E0461175 CONTROL GP-ELECTRONIC (BODY POSITIONER)1
9X5617FILM-INSTRUCTION (SOLENOID, ELECTRICAL POWER)1
7N7782HOUSING-PLUG (14-GA TO 18-GA)1
4D6466176 CLIP3
3S8665177 CLIP (LOOP)2
8M2770178 CLIP (LOOP)3
3T0050179 CLIP1
6K2319180 CLIP1
1058827181 SUPPRESSOR GP-ELECTRONIC (A/C)1
7X1670182 CONTROL GP-ELECTRONIC1
7N7779SOCKET-CONNECTOR (14-GA TO 18-GA)2
7N7780PIN-CONNECTOR (14-GA TO 18-GA)2
7N8205HOUSING-PLUG1
5P1075183 WASHER-HARD (10.2X22.5X3-MM THK)1
1003055184 SENSOR GP-TEMPERATURE (REAR AXLE OIL)1
3J1907185 SEAL-O-RING1
5P9297186 CLIP (LOOP)1
3J7354187 SEAL-O-RING2
9X7781188 SWITCH GP-BYPASS (REAR AXLE OIL FILTER)1
9U2277189 CLIP AS1
1232993190 SWITCH GP-LIQUID LEVEL (REAR AXLE OIL)1
2M9780191 SEAL-O-RING1
7N3718192 CLIP1
1129778193 SENSOR GP-PRESSURE (DIFFERENTIAL OIL)1
9X0262194 ADAPTER1
1358833195 WIRE AS (16-GA, BLACK)1
1028802KIT-RECEPTACLE (2-PIN)1
