System And Components
118-3481 WIRING GP-CAB -PAYLOAD MONITORS/N 5TR1-504
Group No: 118-3481
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X6847 | 1 DISPLAY GP-PAYLOAD MONITOR | 1 | |
| 9X2045 | 2 SCREW-TRUSS HEAD (M6X1X20-MM) | 4 | |
| 3T3046 | 3 CLIP AS | 1 | |
| 9X6846 | 4 CONTROL GP-MONITOR (PAYLOAD) | 1 | |
| 5M3062 | 5 BOLT (3/8-16X0.75-IN) | 14 | |
| 8T4896 | 6 WASHER-HARD (10.2X18.5X2.5-MM THK) | 13 | |
| 9X2044 | 7 SCREW-TRUSS HEAD (M6X1X16-MM) | 2 | |
| 1125572 | 8 SUPPORT | 1 | |
| 1126565 | 9 SUPPORT AS | 1 | |
| 1128242 | 10 INSULATOR | 1 | |
| 1409581 | 11 HARNESS AS-CAB (PAYLOAD MONITOR) | 1 | |
| 3S2093 | 12 STRAP-CABLE | 17 | |
| 1233095 | 13 PANEL | 1 | |
| 8D9537 | 14 CAP-DUST (DOWNLOAD PORT) | 1 | |
| 6D3033 | 15 SCREW-SOCKET HEAD (4-40X0.5-IN) | 4 | |
| 4B5324 | 16 WASHER (3.9X9.6X1.2-MM THK) | 4 | |
| 6B4540 | 17 NUT (4-40-THD) | 4 | |
| 4K5122 | 18 HOLDER AS-FUSE | 1 | |
| 7N2867 | CAP-FUSE HOLDER | 1 | |
| 3K8782 | 19 FUSE (10-AMPERE) | 1 | |
| 3T5438 | 20 DISTRIBUTOR GP-ELECTRONIC (TRANSMISSION SPEED) | 1 | |
| 4M0061 | 21 BOLT (5/16-18X0.75-IN) | 2 | |
| 8T4224 | 22 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8W4812 | 23 BRACKET AS (LAMP BOX) | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | ||
| 8F9836 | BOSS (3/8-16-THD) | 1 | |
| 6G7021 | 24 BRACKET | 1 | |
| 8T9683 | 25 LAMP GP-SIGNAL (RED)(PAYLOAD MONITORING-RED) | 1 | |
| 8T9684 | 26 LAMP GP-SIGNAL (GREEN)(PAYLOAD MONITORING-GREEN) | 1 | |
| 6V2687 | 27 SCREW-PAN HEAD (10-24X1-IN) | 6 | |
| 9F8125 | 28 LOCKWASHER | 6 | |
| 8K1433 | 29 GROMMET | 1 | |
| 9G9150 | 30 CLIP | 2 | |
| 0338248 | 31 CLIP (LOOP) | 1 |
