124-8395 GEAR GP-REAR -CAMSHAFT DRIVES/N 8BR1-UP

Group No: 124-8395
Part NumberPart NameQty
3S13071 BOLT-12 POINT HEAD (3/8-16X2-IN)12
11433722 GEAR AS-CLUSTER (92/35-TEETH)1
10113722A BUSHING1
10113663 SHAFT-GEAR (CLUSTER)1
8M25304 BOLT-12 POINT HEAD (1/2-13X1.25-IN)4
10113655 PLATE-THRUST1
0L13516 BOLT (3/8-16X0.875-IN)4
10113647 GEAR AS-IDLER (69-TEETH)2
12597517A BUSHING1
10113678 SHAFT-IDLER2
5P82489 WASHER-HARD (20X36.5X3.5-MM THK)2
9X888710 BOLT (3/4-10X3-IN)2
1B436711 BOLT (5/8-11X3-IN)4
101136812 WASHER-THRUST (19.5X106X1.9-MM THK)2
101136913 GEAR-CAMSHAFT DRIVE (70-TEETH)2
4W458614 PLATE1
101137015 GEAR-CRANKSHAFT (92-TEETH)1
8S233116 BOLT-12 POINT HEAD (5/8-11X2-IN)2
7E532417 RING1
