System And Components
144-4141 LINES GP-AIR -TURBOCHARGERS/N 2BW1-703
Group No: 144-4141
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W6903 | 1 HOSE | 1 | |
| 4P5104 | 2 ELBOW | 2 | |
| 4P5212 | 3 HOSE | 4 | |
| 4W1211 | 4 STRIP | 4 | |
| 5T6459 | 5 ELBOW | 2 | |
| 5T7873 | 6 BRACKET AS | 2 | |
| 5T7874 | 7 STRAP | 2 | |
| 6I0981 | 8 TUBE AS | 2 | |
| 6I0982 | 9 TUBE AS | 2 | |
| 7C2984 | 10 TUBE | 2 | |
| 7C2985 | 11 ELBOW | 2 | |
| 7N5008 | 12 HOSE | 2 | |
| 8W4379 | 13 SUPPORT AS | 2 | |
| 8W4380 | 14 SUPPORT AS | 2 | |
| 1444143 | 15 TUBE AS | 2 | |
| 2302535 | 16 CLAMP | 4 | |
| 0L1351 | 17 BOLT (3/8-16X0.875-IN) | 8 | |
| 0S1571 | 18 BOLT (3/8-16X1.75-IN) | 4 | |
| 0S1595 | 19 BOLT (1/2-13X1.25-IN) | 4 | |
| 2313264 | 20 CLAMP (BOLT SPRING) | 4 | |
| 2338482 | 21 CLAMP (BOLT SPRING) | 4 | |
| 2338483 | 22 CLAMP (BOLT SPRING) | 8 | |
| 2338484 | 23 CLAMP (BOLT SPRING) | 8 | |
| 2338485 | 24 CLAMP (BOLT SPRING) | 8 | |
| 2402651 | 25 CLAMP | 16 | |
| 2K4973 | 26 LOCKNUT (3/8-16-THD) | 8 | |
| 5M2894 | 27 WASHER-HARD (10.2X18.5X2.5-MM THK) | 16 | |
| 5P8245 | 28 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 6V5048 | 29 SEAL-O-RING | 1 | |
| 7M8485 | 30 SEAL-O-RING | 2 | |
| 8T6764 | 31 PLUG-PIPE (1/8-27-THD) | 2 | |
| 9S4181 | 32 PLUG (1-5/16-12-THD) | 2 | |
| 9S4182 | 33 PLUG (7/16-20-THD) | 1 | |
| 9S8752 | 34 NUT-FULL (3/8-16-THD) | 4 | |
| 9X2494 | 35 U-BOLT | 4 |
