System And Components
272-0287 PIPE GP-EXHAUSTS/N AFS97-UP
Group No: 272-0287
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W8837 | 1 ELBOW AS | 2 | |
| 2W8848 | 2 ELBOW AS | 1 | |
| 2W9067 | 3 SLEEVE AS | 1 | |
| 2W9766 | 4 RING-SEAL | 2 | |
| 5T6432 | 6 ELBOW | 1 | |
| 7K1270 | 7 WASHER (17X38X8-MM THK) | 4 | |
| 8N4401 | 8 CLAMP-V BAND | 2 | |
| 8W5558 | 9 ANGLE | 2 | |
| 1114368 | 10 TUBE AS | 1 | |
| 2312812 | 11 SEAL-RING | 1 | |
| 2471963 | 12 TUBE AS | 1 | |
| 2503871 | 13 TUBE AS | 1 | |
| 2509182 | 14 COVER | 1 | |
| 0S1589 | 15 BOLT (5/8-11X1.75-IN) | 4 | |
| 1A2029 | 16 BOLT (3/8-16X1.125-IN) | 8 | |
| 2W8851 | 17 RING-SEAL | 1 | |
| 4L6454 | 18 BOLT (3/8-16X1-IN) | 2 | |
| 4L9337 | 19 BOLT (3/8-16X1.5-IN) | 4 | |
| 5P8247 | 20 WASHER-HARD (17X32X3.5-MM THK) | 4 | |
| 7K3215 | 21 BOSS (0.413X1X0.630-IN THK) | 2 | |
| 8T2501 | 22 BOLT (3/8-16X2-IN) | 2 | |
| 8T2561 | 23 WASHER-HARD (10.5X28.5X5-MM THK) | 4 | |
| 9X6458 | 24 WASHER-HARD (10.2X22.5X3-MM THK) | 12 |
