System And Components
309-7900 MUFFLER GP -EXTRA QUIETS/N APX1-UP
Group No: 309-7900
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W9766 | 1 RING-SEAL | 2 | |
| 8N4401 | 2 CLAMP-V BAND | 2 | |
| 3092804 | 3 ELBOW AS | 2 | |
| 3092805 | 4 TUBE AS | 2 | |
| 3103172 | 5 SUPPORT AS | 3 | |
| 3103173 | 6 BRACKET AS | 2 | |
| 3103518 | 7 PIPE-EXTENSION | 1 | |
| 3105799 | 8 STRAP AS | 4 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 4 | |
| 3105800 | 9 STRAP AS | 4 | |
| 5G3845 | BOSS (12.8X25X50-MM THK) | 2 | |
| 3107296 | 10 MUFFLER AS | 1 | |
| 3108514 | 11 STRAP AS | 2 | |
| 2W8851 | 12 RING-SEAL | 2 | |
| 4L6454 | 13 BOLT (3/8-16X1-IN) | 18 | |
| 5P1075 | 14 WASHER-HARD (10.2X22.5X3-MM THK) | 30 | |
| 5P1076 | 15 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 6V8188 | 16 NUT (1/2-13-THD) | 2 | |
| 8C4436 | 17 BOLT (1/2-13X1.375-IN) | 6 | |
| 8T2502 | 18 BOLT (3/8-16X1.125-IN) | 4 | |
| 8T4223 | 19 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 8T7008 | 20 BOLT (3/8-16X3-IN) | 8 |
