System And Components
5T-3052 SHAFT GP-DRIVES/N DBB1-UP
Group No: 5T-3052 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2D1523 | 1 RING-RETAINING | 1 | |
| 6G0395 | 2 SHAFT-DRIVE | 1 | |
| 1429961 | 3 HOUSING | 1 | |
| 9F7283 | 4 SEAL-O-RING | 1 | |
| 5S3676 | 5 SEAL-O-RING | 1 | |
| 8W5678 | 6 TUBE AS | 1 | |
| 5P1717 | 8 CLAMP-HOSE | 2 | |
| 8W8136 | 9 COVER | 1 | |
| 7H7628 | 10 BEARING | 1 | |
| 6G0415 | 11 GEAR (27-TEETH) | 1 | |
| 5H6005 | 12 SEAL-O-RING | 2 | |
| 2G1579 | 13 SPACER (3.195-IN THK) | 1 | |
| 1T0334 | 14 BALL BEARING | 1 | |
| 8W8137 | 15 HOUSING | 1 | |
| 8T8916 | 16 BOLT (7/16-14X1.5-IN) | 10 | |
| 8W8139 | 17 DEFLECTOR | 1 | |
| 5D0353 | 18 BOLT-LOCKING (3/8-16X1-IN) | 24 | |
| 8T4896 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 39 | |
| 6D7554 | 20 RETAINER | 1 | |
| 6G0399 | 21 SPRING-DISC | 1 | |
| 6G0389 | 22 SPIDER | 1 | |
| 6G0741 | 23 RETAINER-BEARING | 1 | |
| 6G0391 | 24 RETAINER | 1 | |
| 0308538 | 25 BOLT (1/2-13X1.25-IN) | 2 | |
| 2A4639 | 26 BOLT (3/8-16X1.625-IN) | 4 | |
| 6G0387 | 27 DISC | 2 | |
| 6G8459 | 28 SHAFT AS | 1 | |
| 2D6642 | BALL | 1 | |
| 8D4408 | 29 WASHER-THRUST | 2 | |
| 2K8302 | 30 BEARING | 1 | |
| 9H0846 | 31 SEAL-O-RING | 1 | |
| 8D4409 | 32 GEAR (27-TEETH) | 1 | |
| 1F1006 | 33 DOWEL | 1 | |
| 5K0983 | 34 SEAL-LIP TYPE | 1 | |
| 8W8138 | 35 SHAFT | 1 | |
| 8T4223 | 36 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 1170019 | 37 DISC-FRICTION | 2 | |
| 5T2283 | 38 PLATE AS | 1 | |
| 4H5232 | PIN-SPRING | 3 | |
| 5H4082 | 39 SEAL-O-RING | 1 | |
| 9M5048 | 40 LOCKNUT (7/16-14-THD) | 1 | |
| 6V8188 | 41 NUT (1/2-13-THD) | 6 | |
| 8W4709 | 42 PLATE | 1 | |
| 7X0561 | 43 WASHER-HARD (12X18.5X3-MM THK) | 12 | |
| 6G6492 | 44 RETAINER | 1 | |
| 0T0291 | 45 STUD | 2 | |
| 6V8184 | 46 NUT-FULL (7/16-20-THD) | 2 | |
| 8T2502 | 47 BOLT (3/8-16X1.125-IN) | 11 | |
| 4H5232 | 48 PIN-SPRING | 1 | |
| 7D1677 | 49 RACE-BEARING INNER | 1 | |
| 2949707 | 50 HOSE | 1 |
