System And Components
347-5834 GEAR GP-REARS/N LJW5430-UP
Group No: 347-5834
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N0848 | 1 SLEEVE-WEAR | 1 | |
| 4N7183 | 2 RING-RETAINING | 1 | |
| 5B0213 | 3 BOLT (3/8-16X2.375-IN) | 6 | |
| 5P1370 | 4 BEARING AS-ROLLER | 1 | |
| 7N8525 | 5 WASHER-THRUST | 2 | |
| 1025861 | 6 PLATE-THRUST | 2 | |
| 9S1366 | 8 BOLT (1/2-13X2.5-IN) | 6 | |
| 1293948 | 9 SEAL-INTEGRAL | 1 | |
| 1851497 | 10 GEAR AS-IDLER (79-TEETH) | 1 | |
| 2249664 | BUSHING | 1 | |
| 2014340 | 11 PLUG AS | 1 | |
| 6V4589 | SEAL-O-RING | 1 | |
| 9S8006 | PLUG (7/8-14-THD) | 1 | |
| 2241219 | 12 SHAFT-STUB | 1 | |
| 2241220 | 13 PLATE | 1 | |
| 2241221 | 14 SHAFT-STUB | 1 | |
| 4755915 | 15 PLATE-SEALING | 2 | |
| 2249657 | 16 ADAPTER AS | 2 | |
| 4N0684 | DOWEL | 1 | |
| 2266036 | 17 GEAR AS-IDLER (40/70-TEETH) | 1 | |
| 1B8705 | KEY-WOODRUFF | 1 | |
| 2266052 | BUSHING | 1 | |
| 2285813 | 18 GEAR AS-CRANKSHAFT (49-TEETH) | 1 | |
| 4N0684 | DOWEL | 1 | |
| 2306202 | 19 GEAR AS-IDLER (70/83-TEETH) | 1 | |
| 2098622 | BUSHING | 1 | |
| 2249664 | BUSHING | 1 | |
| 2569650 | 20 GEAR-PUMP (40-TEETH) | 1 | |
| 2569811 | 21 SHAFT-STUB | 1 | |
| 2595771 | 22 ADAPTER | 1 | |
| 2622796 | 23 COVER | 1 | |
| 2816526 | 24 COVER | 1 | |
| 2924486 | 25 SHAFT-STUB | 1 | |
| 2924487 | 26 RETAINER | 1 | |
| 2925517 | 27 TUBE AS | 1 | |
| 2952682 | 28 SHAFT-STUB | 1 | |
| 3201237 | 29 GEAR AS-IDLER (37-TEETH) | 1 | |
| 7N2910 | BUSHING | 1 | |
| 3206198 | 30 GEAR AS-IDLER (57-TEETH) | 1 | |
| 2098621 | BEARING | 1 | |
| 3316188 | 31 GEAR AS-CAMSHAFT (56-TEETH) | 2 | |
| 3473681 | 32 SHAFT AS | 1 | |
| 8T2153 | SETSCREW-SOCKET (1/4-28X0.31-IN) | 1 | |
| 1095724 | 32A SEAL AS (LIP TYPE) | 1 | |
| 3475826 | 33 COVER | 1 | |
| 3475832 | 34 SHAFT | 1 | |
| 3475833 | 35 ADAPTER | 1 | |
| 0310228 | 36 BOLT-12 POINT HEAD (1/2-13X3-IN) | 6 | |
| 0315085 | 37 BOLT-LOCKING (1/4-20X1-IN) | 6 | |
| 0S0509 | 38 BOLT (3/8-16X0.75-IN) | 1 | |
| 0S1585 | 39 BOLT (1/2-13X1.5-IN) | 8 | |
| 0S1590 | 40 BOLT (3/8-16X2-IN) | 6 | |
| 0S1595 | 41 BOLT (1/2-13X1.25-IN) | 4 | |
| 1178801 | 42 SEAL-O-RING | 2 | |
| 1641404 | 43 SPACER (10.67X16.95X23-MM THK) | 1 | |
| 1833408 | 44 PLUG AS | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 2147568 | 45 SEAL-O-RING | 1 | |
| 2453804 | 46 BOLT (3/8-16X3.5-IN) | 1 | |
| 2977956 | 47 ELBOW (INCLUDES SCREEN FILTER) | 1 | |
| 2A4639 | 48 BOLT (3/8-16X1.625-IN) | 1 | |
| 2D8154 | 49 STUD-TAPERLOCK (1/2-13X2.36-IN) | 4 | |
| 3B1915 | 50 BOLT (3/8-16X1.375-IN) | 6 | |
| 5E8771 | 51 SEAL-O-RING | 2 | |
| 5M2894 | 52 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 5P8245 | 53 WASHER-HARD (13.5X25.5X3-MM THK) | 23 | |
| 5P9299 | 54 CLIP (LOOP) | 2 | |
| 6J3913 | 55 BOLT-12 POINT HEAD (5/8-11X3.25-IN) | 12 | |
| 6K3607 | 56 CONNECTOR | 1 | |
| 5024034 | 57 SEAL-O-RING | 1 | |
| 6V4589 | 58 SEAL-O-RING | 1 | |
| 6V5052 | 59 SEAL-O-RING | 1 | |
| 6V5141 | 60 SEAL-O-RING | 2 | |
| 6V7673 | 61 BOLT (M12X1.75X50-MM) | 3 | |
| 6V8188 | 62 NUT (1/2-13-THD) | 4 | |
| 6V8260 | 63 SEAL-O-RING | 1 | |
| 7B3235 | 64 BOLT (1/2-13X1.375-IN) | 16 | |
| 8D0648 | 66 BOLT-12 POINT HEAD (1/2-13X4.5-IN) | 6 | |
| 8T4223 | 67 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 7C1114 | 68 GASKET | 1 | |
| 1095721 | 69 SEAL (DIRT) | 1 |
