System And Components
326-0415 CYLINDER GP-BUCKETS/N KCS1-UP; LJY1-UP
Group No: 326-0415 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4788404 | 1 CYLINDER AS | 1 | |
| 2909180 | 1A BUSHING | 1 | |
| 0950879 | PIN-SPRING | 1 | |
| 7Y0468 | PIN-SPRING | 1 | |
| 3646017 | 2 ROD AS | 1 | |
| 2285617 | 2A BUSHING | 1 | |
| 3646019 | 3 PISTON | 1 | |
| 0951280 | 4 SETSCREW-SOCKET (M16X2X20-MM) | 2 | |
| 1884217 | 5 RING | 2 | |
| 4958212 | 6 SEAL AS | 1 | |
| 4958213 | RING-SEAL | 1 | |
| 4958214 | RING-EXPANDER | 1 | |
| 1884218 | 7 RING | 1 | |
| 3588524 | 8 HEAD | 1 | |
| 7Y4673 | 9 RING-BACKUP | 1 | |
| 0951633 | 10 SEAL-O-RING | 1 | |
| 7Y4672 | 11 RING-RETAINING | 1 | |
| 1140760 | 12 BUSHING | 1 | |
| 3246438 | 13 SEAL-BUFFER | 1 | |
| 3246439 | 14 SEAL-U-CUP | 1 | |
| 7Y4669 | 15 RING-BACKUP | 1 | |
| 1659290 | 16 SEAL-LIP TYPE | 1 | |
| 7Y5215 | 17 BOLT-SOCKET HEAD (M24X3X90-MM) | 8 | |
| 2141639 | 18 MAGNET | 1 | |
| 2433177 | 19 RETAINER | 1 | |
| 3260421 | 20 SENSOR GP-POSITION (BUCKET) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 2151942 | 21 RING-BACKUP | 1 | |
| 1882199 | 22 SEAL-O-RING | 1 | |
| 6V8223 | 23 SETSCREW-SOCKET (M10X1.5X16-MM) | 1 | |
| 1022244 | 24 GROMMET | 1 | |
| 2120907 | 25 PLATE-CONNECTOR | 1 | |
| 1028804 | 26 KIT-RECEPTACLE (4-PIN) | 1 | |
| 8T8737 | 28 PLUG-SEAL | 1 | |
| 3575257 | 29 COVER | 1 | |
| 3V2431 | 30 WASHER (10.2X16X2-MM THK) | 2 | |
| 8T8894 | 31 BOLT-SOCKET HEAD (M10X1.5X20-MM) | 2 | |
| 9X1386 | 32 SLEEVE (6-CM) | ||
| 9X1386 | 32A SLEEVE (8-CM) | ||
| 3E3377 | 33 WEDGE-RECEPTACLE LOCK (4-PIN) | 1 | |
| 5185133 | KIT-SEAL (BUCKET CYLINDER) | 1 |
