System And Components
322-5031 WIRING GP-CABS/N 2YW1-UP
Group No: 322-5031
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2H1855 | 1 SWITCH AS-FOOT (HEAD LIGHT DIMMER) | 1 | |
| 6V8362 | SCREW-MACHINE (8-32X0.31-IN) | 3 | |
| 9B7233 | LOCKWASHER | 3 | |
| 3E2033 | 2 SWITCH AS-PRESSURE (SECONDARY BRAKE) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N9738 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 3E2034 | 3 SWITCH AS-PRESSURE (SERVICE BRAKE, TRACTION CONT) | 1 | |
| 3E2034 | 3A SWITCH AS-PRESSURE (SERVICE BRAKE, TRANSMISSION) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N9738 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 1999850 | 4 CONTROL GP-POWER TRAIN (TRANSMISSION, CHASSIS) | 1 | |
| 3E5184 | 5 CONTROL GP-SECONDARY STEERING | 1 | |
| 3E5239 | 6 RELAY AS (24-VOLT)(BACKUP ALARM) | 1 | |
| 3E5239 | 6A RELAY AS (24-VOLT)(START AID, HOLD) | 1 | |
| 3E5239 | 6B RELAY AS (24-VOLT)(START AID, ON) | 1 | |
| 3E5239 | 6C RELAY AS (24-VOLT)(STOP LIGHT) | 1 | |
| 3E5239 | 6D RELAY AS (24-VOLT)(HEADLIGHTS) | 1 | |
| 3E5239 | 6E RELAY AS (24-VOLT)(MAIN POWER) | 1 | |
| 3E5239 | 6F RELAY AS (24-VOLT)(MAIN POWER) | 1 | |
| 3E5239 | 6G RELAY AS (24-VOLT)(MAIN POWER) | 1 | |
| 3E6328 | 7 ALARM GP (24-VOLT) | 1 | |
| 3T0050 | 8 CLIP | 1 | |
| 3T3046 | 10 CLIP AS | 4 | |
| 3T5438 | 11 DISTRIBUTOR GP-ELECTRONIC | 1 | |
| 4E1411 | 12 BUSHING-TERMINAL | 1 | |
| 5T9327 | 13 GROMMET | 1 | |
| 5V2998 | 14 PLATE | 1 | |
| 6D3033 | 15 SCREW-SOCKET HEAD (4-40X0.5-IN) | 8 | |
| 6G7021 | 16 BRACKET | 1 | |
| 6G9462 | 17 HARNESS AS-WIRING (TURN SIGNAL) | 1 | |
| 6T6117 | 18 SWITCH AS-LIMIT (DOOR) | 1 | |
| 6T3631 | NUT-HEX (15/32-32-THD) | 2 | |
| 6V8373 | SCREW-MACHINE (6-32X0.187-IN) | 2 | |
| 6T7695 | 19 SPEAKER AS-RADIO | 2 | |
| 8C6354 | 20 CAP-RECEPTACLE (ET CONNECTOR) | 1 | |
| 3751478 | 21 LAMP GP-DOME (24-VOLT) | 1 | |
| 8D7712 | 22 FASTENER | 3 | |
| 8D9537 | 23 CAP-DUST | 1 | |
| 8T9683 | 24 LAMP GP-SIGNAL (RED) | 1 | |
| 8T9684 | 25 LAMP GP-SIGNAL (GREEN) | 1 | |
| 8W2066 | 26 LEVER-TURN SIGNAL | 1 | |
| 8W4812 | 27 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 8 | |
| 8F9836 | BOSS (3/8-16-THD) | 1 | |
| 9G8451 | 28 BLOCK AS | 1 | |
| 9G9150 | 29 CLIP | 6 | |
| 9G9154 | 30 CLIP | 2 | |
| 9R7935 | 31 WASHER-SHOULDER (18.5X27X2-MM THK) | 2 | |
| 9R7941 | 32 SOCKET AS | 1 | |
| 9R7980 | COVER | 1 | |
| 9W3072 | 33 ANTENNA AS | 1 | |
| 9X0435 | 34 ADAPTER | 1 | |
| 9X6846 | 35 CONTROL GP-MONITOR (PAYLOAD) | 1 | |
| 9X6847 | 36 DISPLAY GP-PAYLOAD MONITOR | 1 | |
| 1034977 | 37 SWITCH AS-PRESSURE (RETARDER) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 1035526 | 38 CONTROL GP-MONITOR (BACKLIGHT DIMMER) | 1 | |
| 1080358 | 39 FLASHER AS (24-VOLT) | 1 | |
| 1125572 | 40 SUPPORT | 3 | |
| 1126565 | 41 SUPPORT AS | 3 | |
| 1128242 | 42 INSULATOR | 3 | |
| 1135886 | 43 PANEL GP-CIRCUIT BREAKER | 1 | |
| 1157879 | 44 PLATE AS | 1 | |
| 7T1099 | LINK | 2 | |
| 1160118 | 45 CLIP | 1 | |
| 1169304 | 46 HARNESS AS-CAB (MONITOR INTERFACE) | 1 | |
| 2L8079 | TERMINAL-RING (14-GA TO 16-GA, 3/8-IN SCREW) | 1 | |
| 7X6222 | PLUG AS-CONNECTOR (24-PIN) | 1 | |
| 3E4367 | RING-RETAINING | 1 | |
| 3E8558 | BOLT (M5X0.8X39.37-MM) | 1 | |
| 9X3265 | SEAL-CONNECTOR (24-PIN) | 2 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 28 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 18 | |
| 8T8737 | PLUG-SEAL | 26 | |
| 9X0146 | RECEPTACLE AS-CONNECTOR (24-PIN) | 1 | |
| 9X7145 | RECEPTACLE AS-CONNECTOR (24-PIN) | 1 | |
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(10-CM) | ||
| 1169306 | 47 HARNESS AS-CAB (OVERHEAD) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 1552274 | KIT-CONNECTING PLUG (6-PIN) | 1 | |
| 1552265 | KIT-CONNECTING PLUG (8-PIN) | 1 | |
| 1552255 | KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 6T8047 | HOUSING-RECEPTACLE (BLADE, POSITIVE LOCK) | 2 | |
| 6T8048 | TERMINAL-RECEPTACLE (16-GA TO 20-GA) | 2 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 2 | |
| 7N7781 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 5P4571 | TERMINAL-BLADE (14-GA TO 16-GA) | 2 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 22 | |
| 8T8737 | PLUG-SEAL | 5 | |
| 9W0844 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 1 | |
| 1193662 | TUBE-HEAT SHRINK (10.85-MM DIA)(7-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(15-CM) | ||
| 1172929 | 48 HARNESS AS-ENGINE | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 2 | |
| 1552271 | KIT-CONNECTING PLUG (4-PIN) | 1 | |
| 1552265 | KIT-CONNECTING PLUG (8-PIN) | 1 | |
| 7G7917 | PLUG-SEAL | 22 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 3 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 3 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 7N9738 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 2 | |
| 8N1514 | PLUG AS-CONNECTOR (37-PIN) | 1 | |
| 8N1521 | BELL AS-END | 1 | |
| 9X6857 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 15 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 6 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 13 | |
| 8T8737 | PLUG-SEAL | 3 | |
| 9G3673 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 9G3695 | PLUG-SEAL | 8 | |
| 1193662 | TUBE-HEAT SHRINK (10.85-MM DIA)(7-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(5-CM) | ||
| 1172932 | 49 CABLE AS-COAXIAL | 1 | |
| 1172933 | 50 HARNESS AS-ENGINE | 1 | |
| 1552274 | KIT-CONNECTING PLUG (6-PIN) | 1 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 5 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 1193662 | TUBE-HEAT SHRINK (10.85-MM DIA)(7-CM) | ||
| 1233095 | 51 PANEL | 1 | |
| 1246704 | 52 RESISTOR AS (ETHER SOLENOID LOAD) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 5P6008 | TUBE-HEAT SHRINK (6.35-MM DIA)(1-CM) | ||
| 8C3334 | RIVET-TUBULAR | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 1268865 | 53 HARNESS AS-CAB (TRACTION CONTROL) | 1 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | ||
| 7G7917 | PLUG-SEAL | 24 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 3 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 8N1514 | PLUG AS-CONNECTOR (37-PIN) | 1 | |
| 8N1521 | BELL AS-END | 1 | |
| 9X6857 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 13 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 16 | |
| 9G3673 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 9G3695 | PLUG-SEAL | 6 | |
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(5-CM) | ||
| 1362238 | 54 CONTROL GP-TRACTION ELECTRONIC | 1 | |
| 1409581 | 55 HARNESS AS-CAB (PAYLOAD MONITOR) | 1 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 1038133 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 2L8079 | TERMINAL-RING (14-GA TO 16-GA, 3/8-IN SCREW) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 6 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 6 | |
| 1552274 | KIT-CONNECTING PLUG (6-PIN) | 1 | |
| 7N9737 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 7N9738 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 8N1525 | PLUG AS-CONNECTOR (20-PIN) | 1 | |
| 8N1535 | BELL AS-END | 1 | |
| 9X6857 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 20 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 9 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 4 | |
| 8T8737 | PLUG-SEAL | 5 | |
| 9D3374 | RECEPTACLE AS-CONNECTOR (5-PIN) | 1 | |
| 9G3673 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 9G3695 | PLUG-SEAL | 2 | |
| 1193662 | TUBE-HEAT SHRINK (10.85-MM DIA)(7-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(15-CM) | ||
| 1P0810 | TAPE-ELECTRICAL (42-CM) | ||
| 1422658 | 56 HARNESS AS-CAB (MAIN) | 1 | |
| 2L8065 | TERMINAL-RING (10-GA TO 12-GA, NO. 8 SCREW) | 1 | |
| 2L8075 | TERMINAL-RING (14-GA TO 16-GA, NO. 8 SCREW) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 1740503 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 1552271 | KIT-CONNECTING PLUG (4-PIN) | 1 | |
| 1552274 | KIT-CONNECTING PLUG (6-PIN) | 1 | |
| 1552265 | KIT-CONNECTING PLUG (8-PIN) | 1 | |
| 1552255 | KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 1106844 | SEAL | 1 | |
| 1106845 | PLUG AS-CONNECTOR (40-PIN) | 1 | |
| 9X0194 | TERMINAL AS | 1 | |
| 9G4343 | TERMINAL-RING (4-GA, 1/4-IN SCREW) | 1 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 1028806 | KIT-RECEPTACLE (8-PIN) | 1 | |
| 6T6505 | HOUSING-RECEPTACLE (BLADE, POSITIVE LOCK) | 2 | |
| 6T6506 | TERMINAL-BLADE (14-GA TO 18-GA) | 2 | |
| 2L8058 | TERMINAL-RING (8-GA, 1/4-IN SCREW) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 14 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 11 | |
| 7N9737 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 4 | |
| 7N9738 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 8N1517 | RECEPTACLE AS-CONNECTOR (25-PIN) | 1 | |
| 8N1522 | NUT (2-1/4-16-THD) | 1 | |
| 8N1521 | BELL AS-END | 1 | |
| 8N1523 | LOCKWASHER | 1 | |
| 8N1548 | PIN-CONNECTOR (4-GA) | 2 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 140 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 67 | |
| 8T8732 | RECEPTACLE-CONNECTOR (3-PIN) | 1 | |
| 8T8737 | PLUG-SEAL | 80 | |
| 9G3670 | HOUSING-PLUG | 1 | |
| 9G3673 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 9G3676 | HOUSING-RECEPTACLE | 2 | |
| 9G3695 | PLUG-SEAL | 16 | |
| 9W0844 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 9 | |
| 9W0852 | PIN-CONNECTOR (14-GA TO 16-GA) | 13 | |
| 9W1951 | RECEPTACLE AS-CONNECTOR (9-PIN) | 1 | |
| 9X0146 | RECEPTACLE AS-CONNECTOR (24-PIN) | 2 | |
| 9X1054 | PLUG AS-CONNECTOR (4-PIN) | 4 | |
| 9X1055 | TERMINAL-RECEPTACLE (12-GA) | 5 | |
| 9X1056 | TERMINAL-RECEPTACLE (14-GA TO 16-GA) | 11 | |
| 9X7143 | RECEPTACLE AS-CONNECTOR (24-PIN) | 1 | |
| 9X7148 | RECEPTACLE AS-CONNECTOR (40-PIN) | 1 | |
| 1130580 | RECEPTACLE AS-CONNECTOR (40-PIN) | 1 | |
| 1064155 | KIT-RETAINING BOLT | 1 | |
| 1193662 | TUBE-HEAT SHRINK (10.85-MM DIA)(98-CM) | ||
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 8T8737 | PLUG-SEAL | 2 | |
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(80-CM) | ||
| 1533962 | 57 SENSOR GP-PRESSURE (AIR) | 1 | |
| 2L3402 | 58 SWITCH AS (PRESSURE)(STOP LIGHT) | 1 | |
| 6V8376 | SCREW-MACHINE (8-32X0.25-IN) | 2 | |
| 1733064 | 59 SWITCH GP-ROTARY (TURN SIGNAL, HAZARD) | 1 | |
| 5L7200 | SCREW (8-32X0.375-IN) | 1 | |
| 9B7233 | LOCKWASHER | 1 | |
| 1754827 | 60 HARNESS AS-TRANSMISSION | 1 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 3S2093 | STRAP-CABLE | 1 | |
| 2L8079 | TERMINAL-RING (14-GA TO 16-GA, 3/8-IN SCREW) | 2 | |
| 7G7917 | PLUG-SEAL | 7 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 6 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 4 | |
| 7N8204 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 7X6222 | PLUG AS-CONNECTOR (24-PIN) | 1 | |
| 3E4367 | RING-RETAINING | 1 | |
| 3E8558 | BOLT (M5X0.8X39.37-MM) | 1 | |
| 9X3265 | SEAL-CONNECTOR (24-PIN) | 2 | |
| 8N1514 | PLUG AS-CONNECTOR (37-PIN) | 1 | |
| 8N1521 | BELL AS-END | 1 | |
| 9X6857 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 30 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 21 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 19 | |
| 9G3673 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 9G3695 | PLUG-SEAL | 14 | |
| 9X0145 | RECEPTACLE AS-CONNECTOR (24-PIN) | 1 | |
| 1893158 | SUPPRESSOR-ARC | 1 | |
| 1193662 | TUBE-HEAT SHRINK (10.85-MM DIA)(7-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(25-CM) | ||
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 1 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 1 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 10 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 3407160 | 61 CONVERTER-POWER (24-VOLT TO 12-VOLT) | 1 | |
| 0338248 | 62 CLIP (LOOP) | 1 | |
| 1893158 | 63 SUPPRESSOR-ARC | 1 | |
| 1S0994 | 64 CLIP (LOOP) | 2 | |
| 2N3479 | 65 SCREW (10-24X0.5-IN) | 8 | |
| 3J7354 | 66 SEAL-O-RING | 1 | |
| 3P3839 | 67 GROMMET | 1 | |
| 3S2093 | 68 STRAP-CABLE | 42 | |
| 3S8665 | 69 CLIP (LOOP) | 1 | |
| 4B1229 | 70 SCREW (10-24X12.7-MM) | 2 | |
| 4B4274 | 71 WASHER (5.5X13X1.2-MM THK) | 2 | |
| 4M0061 | 72 BOLT (5/16-18X0.75-IN) | 2 | |
| 4P7581 | 73 CLIP (LADDER) | 1 | |
| 4S1962 | 74 CLIP (LOOP) | 1 | |
| 5C9553 | 75 BOLT (M6X1X16-MM) | 2 | |
| 5L4507 | 76 SCREW-MACHINE (10-32X0.875-IN) | 3 | |
| 5M3062 | 77 BOLT (3/8-16X0.75-IN) | 37 | |
| 5P1075 | 78 WASHER-HARD (10.2X22.5X3-MM THK) | 4 | |
| 5P2675 | 79 BOLT (1/4-20X1.75-IN) | 2 | |
| 5P4115 | 80 WASHER-HARD (7.2X19X2-MM THK) | 2 | |
| 5P7854 | 81 CLIP (LOOP) | 1 | |
| 5S4246 | 82 LOCKWASHER | 8 | |
| 5S7349 | 83 BOLT (1/4-20X0.5-IN) | 9 | |
| 5S7379 | 84 BOLT (3/8-16X0.875-IN) | 4 | |
| 6B4540 | 85 NUT (4-40-THD) | 8 | |
| 6V2687 | 86 SCREW-PAN HEAD (10-24X1-IN) | 6 | |
| 7K1181 | 87 STRAP-CABLE | 22 | |
| 8C9660 | 88 WASHER (4.6X7.9X0.8-MM THK) | 16 | |
| 8K1433 | 89 GROMMET | 1 | |
| 8M2773 | 90 CLIP (LOOP) | 1 | |
| 8T0328 | 91 WASHER-HARD (5.5X10X1-MM THK) | 5 | |
| 8T9394 | 92 BOLT-SOCKET HEAD (10-24X0.5-IN) | 5 | |
| 8T4205 | 93 WASHER-HARD (7.2X14.5X2-MM THK) | 11 | |
| 8T4224 | 94 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T4896 | 95 WASHER-HARD (10.2X18.5X2.5-MM THK) | 34 | |
| 8T9364 | 96 BOLT (1/4-20X0.625-IN) | 2 | |
| 1622165 | 97 BOLT-SOCKET HEAD (M4X0.7X16-MM) | 16 | |
| 9D8508 | 98 GROMMET | 1 | |
| 0960192 | 99 LOCKWASHER | 12 | |
| 9M8406 | 100 CLIP (LOOP) | 1 | |
| 9X2042 | 101 SCREW-TRUSS HEAD (M6X1X12-MM) | 4 | |
| 9X2044 | 102 SCREW-TRUSS HEAD (M6X1X16-MM) | 6 | |
| 9X2045 | 103 SCREW-TRUSS HEAD (M6X1X20-MM) | 4 | |
| 9X8256 | 104 WASHER (6.6X12X2-MM THK) | 2 |
