System And Components
260-7256 BELT TENSIONER GPS/N RCY1-UP
Group No: 260-7256
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2N2280 | 1 LOCKNUT | 1 | |
| 2478270 | 2 SPRING AS | 1 | |
| 8N5579 | 3 RETAINER | 1 | |
| 1D5117 | 4 NUT-JAM (1/2-13-THD) | 1 | |
| 2M2742 | 5 PLATE-RETAINER | 1 | |
| 5S7379 | 6 BOLT (3/8-16X0.875-IN) | 2 | |
| 8T4896 | 7 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 1S8687 | 8 SPACER (25.5X33.4X31.75-MM THK) | 1 | |
| 8B2327 | 9 RING-RETAINING | 1 | |
| 6B1124 | 10 BALL BEARING | 2 | |
| 2S6150 | 11 COVER-PULLEY | 1 | |
| 2S6160 | 12 WASHER-HARD (10.2X32X5-MM THK) | 1 | |
| 4M6425 | 13 BOLT (5/16-18X1-IN) | 4 | |
| 4N2697 | 14 PULLEY-TIGHTENER (3-GROOVE) | 1 | |
| 5M9735 | 15 SEAL-LIP TYPE | 1 | |
| 4S7916 | 16 SPACER-SPECIAL | 1 | |
| 3B4617 | 17 PIN-COTTER | 1 | |
| 4N2693 | 18 ARM AS-TIGHTENER | 1 | |
| 4S5367 | BUSHING AS (MOUNT) | 1 | |
| 4N0955 | DOWEL | 1 | |
| 4L9337 | 19 BOLT (3/8-16X1.5-IN) | 4 | |
| 4N2690 | 20 SHAFT AS | 1 | |
| 1S9209 | SHAFT-TIGHTENER | 1 | |
| 4N0955 | DOWEL | 1 | |
| 2S6151 | 21 GASKET | 1 | |
| 8T4223 | 22 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 2M0849 | 23 WASHER-HARD (13.5X25.5X5-MM THK) | 1 | |
| 6S6308 | 24 PIN | 1 | |
| 8N5581 | 25 STUD | 1 | |
| 2987658 | 26 KIT-SHIM | 1 | |
| 4W5746 | KIT-BEARING | 1 |
