System And Components
1W-4933 BELT TENSIONER GPS/N 7CG1-99999
Group No: 1W-4933
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2N2280 | 1 LOCKNUT | 1 | |
| 4L9337 | 2 BOLT (3/8-16X1.5-IN) | 3 | |
| 4N2697 | 3 PULLEY-TIGHTENER | 1 | |
| 4M6425 | 4 BOLT (5/16-18X1-IN) | 4 | |
| 8B2327 | 5 RING-RETAINING | 1 | |
| 1753846 | 6 ARM AS | 1 | |
| 4N0955 | DOWEL | 1 | |
| 4S5367 | BUSHING AS (MOUNT) | 1 | |
| 2S1511 | 7 HOSE AS | 1 | |
| 3B8485 | 8 ELBOW | 1 | |
| 6V8188 | 9 NUT (1/2-13-THD) | 1 | |
| 8T4223 | 10 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8N5579 | 11 RETAINER | 1 | |
| 2010357 | 12 ABSORBER AS-SHOCK | 1 | |
| 5M9735 | 13 SEAL-LIP TYPE | 1 | |
| 4S7916 | 14 SPACER-SPECIAL | 1 | |
| 6S6308 | 15 PIN | 1 | |
| 3B4617 | 16 PIN-COTTER | 1 | |
| 2M2742 | 17 PLATE-RETAINER | 1 | |
| 5S7379 | 18 BOLT (3/8-16X0.875-IN) | 2 | |
| 8T4896 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 3B6552 | 20 ELBOW-PIPE | 1 | |
| 8N5581 | 21 STUD | 1 | |
| 1W4693 | 22 SHAFT AS | 1 | |
| 4N0955 | DOWEL | 1 | |
| 1S9209 | SHAFT-TIGHTENER | 1 | |
| 7X0592 | 23 WASHER-HARD (10.2X32X5-MM THK) | 1 | |
| 2S6150 | 24 COVER-PULLEY | 1 | |
| 2S6151 | 25 GASKET | 1 | |
| 6B1124 | 26 BALL BEARING | 2 | |
| 1S8687 | 27 SPACER (25.5X33.4X31.75-MM THK) | 1 |
