System And Components
Assembly
100%

576-7319 WIRING GP-ENGINEAN ATTACHMENT

Group No: 576-7319
Part NumberPart NameQty
16199261 SENSOR GP-PRESSURE (CRANKCASE)1
16199261A SENSOR GP-PRESSURE (ATMOSPHERIC AIR)1
25373902 HARNESS AS-ENGINE1
4P70683 BRACKET1
7K11814 STRAP-CABLE31
9G51275 BREATHER (ATMOSPHERIC)1
9X67726 STRAP-CABLE47
10222407 SENSOR GP-TEMPERATURE (3-PIN)(COOLANT)1
10222407A SENSOR GP-TEMPERATURE (3-PIN)(AFTERCOOLER)1
11136848 HOSE AS1
19467249 SENSOR GP-PRESSURE (TURBOCHARGER OUTLET)1
194672510 SENSOR GP-PRESSURE (FILTERED FUEL)1
194672510A SENSOR GP-PRESSURE (UNFILTERED FUEL)1
194672510B SENSOR GP-PRESSURE (FILTERED OIL)1
194672510C SENSOR GP-PRESSURE (UNFILTERED FUEL)1
522164311 SENSOR GP-SPEED (PRIMARY, TIMING)1
522164311A SENSOR GP-SPEED (SECONDARY, TIMING)1
318118112 SENSOR GP-SPEED (MAGNETIC)(ENGINE)1
318118112A SENSOR GP-SPEED (MAGNETIC)(TIMING CALIBRATION)1
415242813 SENSOR GP-EXHAUST TEMPERATURE (TURBOCHARGER INLET, LH)1
415242813A SENSOR GP-EXHAUST TEMPERATURE (TURBOCHARGER INLET, RH)1
001944014 CONNECTOR1
165393315 BOLT (3/8-16X2.25-IN)6
0S050916 BOLT (3/8-16X0.75-IN)9
0S159417 BOLT (3/8-16X1-IN)4
117006718 ELBOW1
2H385519 BOLT (1/2-13X0.875-IN)2
3A369220 CLIP2
3B191521 BOLT (3/8-16X1.375-IN)8
3K036022 SEAL-O-RING2
4B428123 WASHER (16.8X33X2.5-MM THK)1
4P742824 CLIP (LADDER)2
4P758125 CLIP (LADDER)14
4P813426 CLIP (LADDER)47
5M289427 WASHER-HARD (10.2X18.5X2.5-MM THK)35
279049628 HARNESS AS-SENSOR1
5P342629 ELBOW1
5P824530 WASHER-HARD (13.5X25.5X3-MM THK)2
6V504831 SEAL-O-RING15
6W667232 SPACER (10.5X20X38-MM THK)6
9M459433 SPACER (0.406X0.875X0.75-IN THK)8
9S875234 NUT-FULL (3/8-16-THD)1
9X026235 ADAPTER6
368501136 BRACKET1
279049737 HARNESS AS-SENSOR1
