System And Components
371-8458 LINES GP-ENGINE OIL DRAIN -CLOSED CRANKCASE VENTILATIONAN ATTACHMENT
Group No: 371-8458
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P7233 | 1 GROMMET | 6 | |
| 3441950 | 2 CLIP (SLOT) | 2 | |
| 3529919 | 3 VALVE AS-CHECK | 2 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3664677 | 4 TEE AS | 1 | |
| 6V9837 | TEE-SWIVEL | 1 | |
| 1808424 | SEAL-O-RING | 2 | |
| 3744290 | 5 HOSE & TUBE AS | 1 | |
| 1226870 | HOSE-HYDRAULIC (12.2-IN) | ||
| 1241961 | COUPLING-PERMANENT | 1 | |
| 3744292 | 6 HOSE & TUBE AS | 1 | |
| 1226870 | HOSE-HYDRAULIC (12.2-IN) | ||
| 1241961 | COUPLING-PERMANENT | 1 | |
| 3744294 | 7 HOSE & TUBE AS | 1 | |
| 1226870 | HOSE-HYDRAULIC (12.2-IN) | ||
| 1241961 | COUPLING-PERMANENT | 1 | |
| 3744296 | 8 HOSE & TUBE AS | 1 | |
| 1226870 | HOSE-HYDRAULIC (12.2-IN) | ||
| 1241961 | COUPLING-PERMANENT | 1 | |
| 3744301 | 9 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 3744341 | 10 BRACKET AS | 4 | |
| 3744350 | 11 BRACKET AS | 1 | |
| 3745029 | 12 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 3745054 | 13 BRACKET AS | 1 | |
| 0922467 | 14 SPACER (10.5X2X45-MM THK) | 1 | |
| 0S0509 | 15 BOLT (3/8-16X0.75-IN) | 2 | |
| 0S1590 | 16 BOLT (3/8-16X2-IN) | 3 | |
| 0S1594 | 17 BOLT (3/8-16X1-IN) | 10 | |
| 0T0573 | 18 BOLT (3/8-16X2.75-IN) | 1 | |
| 2287090 | 19 SEAL-O-RING | 2 | |
| 3328542 | 20 TEE AS | 1 | |
| 6V9844 | TEE-SWIVEL | 1 | |
| 2287090 | SEAL-O-RING | 2 | |
| 3441951 | 21 CLIP (TAB) | 2 | |
| 5M2894 | 22 WASHER-HARD (10.2X18.5X2.5-MM THK) | 16 | |
| 7C8246 | 23 SPACER (10.5X20X24-MM THK) | 3 | |
| 8T1887 | 24 CLIP (SLOT) | 6 | |
| 8T1888 | 25 CLIP (TAB) | 6 |
