System And Components
194-6715 BELT TENSIONER GPS/N ALP1-UP
Group No: 194-6715
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1753846 | 1 ARM AS | 1 | |
| 4N0955 | 1A DOWEL | 1 | |
| 4S5367 | 1B BUSHING AS (MOUNT) | 1 | |
| 1S8687 | 2 SPACER (25.5X33.4X31.75-MM THK) | 1 | |
| 1W4693 | 3 SHAFT AS | 1 | |
| 4N0955 | 3A DOWEL | 1 | |
| 1W4690 | 3B FLANGE-SHAFT | 1 | |
| 2M2742 | 4 PLATE-RETAINER | 1 | |
| 2S6150 | 5 COVER-PULLEY | 1 | |
| 2S6151 | 6 GASKET | 1 | |
| 3B6552 | 7 ELBOW-PIPE | 1 | |
| 3B8485 | 8 ELBOW (BELT TIGHTENER) | 1 | |
| 4N2697 | 9 PULLEY-TIGHTENER (3-GROOVE) | 1 | |
| 4S7916 | 10 SPACER-SPECIAL | 1 | |
| 5M9735 | 11 SEAL-LIP TYPE | 1 | |
| 6B1124 | 12 BALL BEARING | 2 | |
| 8B2327 | 13 RING-RETAINING | 1 | |
| 8N5579 | 14 RETAINER | 1 | |
| 8N5581 | 15 STUD | 1 | |
| 2010357 | 16 ABSORBER AS-SHOCK | 1 | |
| 1393261 | 17 HOSE AS | 1 | |
| 2N2280 | 18 LOCKNUT | 1 | |
| 3B4617 | 19 PIN-COTTER | 1 | |
| 0S1591 | 20 BOLT (3/8-16X1.5-IN) | 3 | |
| 0S1618 | 21 BOLT (5/16-18X1-IN) | 4 | |
| 0L1351 | 22 BOLT (3/8-16X0.875-IN) | 2 | |
| 6S6308 | 23 PIN | 1 | |
| 1F7958 | 24 NUT-FULL (1/2-13-THD) | 1 | |
| 2S6160 | 25 WASHER-HARD (10.2X32X5-MM THK) | 1 | |
| 5P8245 | 26 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 5M2894 | 27 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 |
