System And Components
161-6634 PUMP GP-PISTONS/N 2CR16212-19309
Group No: 161-6634
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6E3343 | 1 RING | 1 | |
| 6E4003 | 2 BEARING | 2 | |
| 1730637 | 3 HOUSING-PUMP | 1 | |
| 1205726 | 4 ROTATING GP-PUMP | 1 | |
| 3E6769 | 5 SEAL-O-RING (17MM ID) | 4 | |
| 0959805 | 6 BOLT-SOCKET HEAD (M14X2X40-MM) | 4 | |
| 1P6872 | 7 CUP-BEARING | 1 | |
| 8C7110 | 8 CONE-BEARING | 1 | |
| 1035520 | 9 CARRIER-PIN | 1 | |
| 6E4000 | 10 SPACER (25.5X35X3-MM THK) | 1 | |
| 3E6770 | 11 SEAL-O-RING | 1 | |
| 6E6175 | 12 CYLINDER | 1 | |
| 6E6176 | 13 SPRING | 1 | |
| 6E6174 | 14 PLUNGER | 1 | |
| 9S8006 | 15 PLUG (7/8-14-THD) | 1 | |
| 2M9780 | 16 SEAL-O-RING | 1 | |
| 1621604 | 17 SHAFT-DRIVE | 1 | |
| 6V2323 | 18 CONE-BEARING | 1 | |
| 3B5790 | 19 CUP-BEARING | 1 | |
| 6E4004 | 20 SEAL-SHAFT | 2 | |
| 1730639 | 21 SWASHPLATE AS | 1 | |
| 1205727 | 22 PISTON-CONTROL | 1 | |
| 1205729 | 23 GUIDE-PISTON | 1 | |
| 1368423 | 24 PLUG-BREAK OFF | 1 | |
| 0834419 | 25 PIN | 1 | |
| 1730641 | 26 PLUG-FILTER | 1 | |
| 1730638 | 27 HEAD-PUMP | 1 | |
| 1035522 | 28 ADAPTER AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 3J7352 | 29 CONNECTOR | 2 | |
| 3J7354 | 30 SEAL-O-RING | 3 | |
| 1938648 | 31 TUBE AS | 1 | |
| 1035519 | 32 VALVE GP-PUMP CONTROL (POWER COMPENSATOR) | 1 | |
| 6V5683 | 33 BOLT (M6X1X16-MM) | 1 | |
| 3C8388 | 34 PIN-ROLL | 1 | |
| 1730640 | 35 VALVE GP-PUMP CONTROL (PRESSURE, FLOW COMPENSATOR) | 1 |
