System And Components
245-9776 GEAR GP-REARS/N MHM1-UP; MZM1-UP
Group No: 245-9776
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N0848 | 1 SLEEVE-WEAR | 1 | |
| 5B0213 | 2 BOLT (3/8-16X2.375-IN) | 6 | |
| 1025861 | 3 PLATE-THRUST | 2 | |
| 1851497 | 4 GEAR AS-IDLER (79-TEETH) | 1 | |
| 2249664 | BUSHING | 1 | |
| 2241219 | 5 SHAFT-STUB | 1 | |
| 2241220 | 6 PLATE | 1 | |
| 2241221 | 7 SHAFT-STUB | 1 | |
| 2245332 | 8 PLATE-SEALING | 2 | |
| 2249657 | 9 ADAPTER AS | 2 | |
| 4N0684 | DOWEL | 1 | |
| 2266036 | 10 GEAR AS-IDLER (40/70-TEETH) | 1 | |
| 1B8705 | KEY-WOODRUFF | 1 | |
| 2266052 | BUSHING | 1 | |
| 2270159 | 11 SHAFT-STUB | 1 | |
| 2285813 | 12 GEAR AS-CRANKSHAFT (49-TEETH) | 1 | |
| 4N0684 | DOWEL | 1 | |
| 2291663 | 13 PLATE-THRUST | 1 | |
| 2306202 | 14 GEAR AS-IDLER (70/83-TEETH) | 1 | |
| 2249664 | 14A BUSHING | 1 | |
| 3316188 | 15 GEAR AS-CAMSHAFT (56-TEETH) | 2 | |
| 0315085 | 16 BOLT-LOCKING (1/4-20X1-IN) | 6 | |
| 1178801 | 17 SEAL-O-RING | 2 | |
| 1A2029 | 18 BOLT (3/8-16X1.125-IN) | 4 | |
| 2453804 | 19 BOLT (3/8-16X3.5-IN) | 1 | |
| 5E8771 | 20 SEAL-O-RING | 2 | |
| 6J3913 | 21 BOLT-12 POINT HEAD (5/8-11X3.25-IN) | 12 | |
| 6V3319 | 22 SEAL-O-RING | 1 | |
| 7B3235 | 23 BOLT (1/2-13X1.375-IN) | 8 |
