System And Components
399-5083 GEAR GP-REARS/N AT41-UP
Group No: 399-5083
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N0848 | 1 SLEEVE-WEAR | 1 | |
| 4N7183 | 2 RING-RETAINING | 2 | |
| 5F7403 | 4 LOCKWASHER | 2 | |
| 5F7404 | 5 LOCKNUT-BEARING | 2 | |
| 5P1370 | 6 BEARING AS-ROLLER | 2 | |
| 1025861 | 7 PLATE-THRUST | 2 | |
| 1851497 | 8 GEAR AS-IDLER (79-TEETH) | 1 | |
| 2249664 | 8A BUSHING | 1 | |
| 1940620 | 9 HOSE AS | 2 | |
| 2177219 | 10 ADAPTER-HYDRAULIC PUMP | 2 | |
| 2223920 | 11 GEAR (49-TEETH) | 2 | |
| 2241219 | 12 SHAFT-STUB | 1 | |
| 2241220 | 13 PLATE | 1 | |
| 2241221 | 14 SHAFT-STUB | 1 | |
| 4755915 | 15 PLATE-SEALING | 2 | |
| 2249657 | 16 ADAPTER AS | 2 | |
| 4N0684 | DOWEL | 1 | |
| 2266036 | 17 GEAR AS-IDLER (40/70-TEETH) | 1 | |
| 1B8705 | KEY-WOODRUFF | 1 | |
| 2266052 | 17A BUSHING | 1 | |
| 2270159 | 18 SHAFT-STUB | 1 | |
| 2285813 | 19 GEAR AS-CRANKSHAFT (49-TEETH) | 1 | |
| 4N0684 | DOWEL | 1 | |
| 2291663 | 20 PLATE-THRUST | 1 | |
| 2306202 | 21 GEAR AS-IDLER (70/83-TEETH) | 1 | |
| 2249664 | 21A BUSHING | 1 | |
| 3316188 | 22 GEAR AS-CAMSHAFT (56-TEETH) | 2 | |
| 3235665 | PIN-DOWEL | 1 | |
| 0315085 | 23 BOLT-LOCKING (1/4-20X1-IN) | 6 | |
| 0S1588 | 24 BOLT (3/8-16X1.25-IN) | 3 | |
| 1178801 | 26 SEAL-O-RING | 2 | |
| 1325789 | 27 CLIP (LADDER) | 1 | |
| 1A2029 | 28 BOLT (3/8-16X1.125-IN) | 13 | |
| 1T0720 | 29 BOLT-12 POINT HEAD (3/8-16X1.25-IN) | 12 | |
| 2147568 | 30 SEAL-O-RING | 2 | |
| 2453804 | 31 BOLT (3/8-16X3.5-IN) | 1 | |
| 2977956 | 32 ELBOW (INCLUDES SCREEN FILTER) | 2 | |
| 4P7428 | 33 CLIP (LADDER) | 2 | |
| 5B0213 | 35 BOLT (3/8-16X2.375-IN) | 6 | |
| 5E8771 | 36 SEAL-O-RING | 2 | |
| 5P4318 | 37 ELBOW | 2 | |
| 5P8429 | 39 SEAL-O-RING | 2 | |
| 6J3913 | 40 BOLT-12 POINT HEAD (5/8-11X3.25-IN) | 12 | |
| 5024034 | 41 SEAL-O-RING | 1 | |
| 6V4589 | 42 SEAL-O-RING | 2 | |
| 6V5839 | 43 WASHER (11X21X2.5-MM THK) | 3 | |
| 7B3235 | 44 BOLT (1/2-13X1.375-IN) | 8 |
