System And Components
208-5481 GEAR GP-REARS/N WZH1-UP
Group No: 208-5481
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N0848 | 1 SLEEVE-WEAR | 1 | |
| 4N7183 | 2 RING-RETAINING | 2 | |
| 5B0213 | 3 BOLT (3/8-16X2.375-IN) | 6 | |
| 5P1370 | 4 BEARING AS-ROLLER | 2 | |
| 7N8525 | 5 WASHER-THRUST | 2 | |
| 1025861 | 6 PLATE-THRUST | 2 | |
| 1851497 | 7 GEAR AS-IDLER (79-TEETH) | 1 | |
| 2249664 | 7A BUSHING | 1 | |
| 3176539 | 8 SEAL-LIP TYPE | 1 | |
| 2241219 | 9 SHAFT-STUB | 1 | |
| 2241220 | 10 PLATE | 1 | |
| 2241221 | 11 SHAFT-STUB | 1 | |
| 4755915 | 12 PLATE-SEALING | 2 | |
| 2249657 | 13 ADAPTER AS | 2 | |
| 4N0684 | 13A DOWEL | 1 | |
| 2266036 | 14 GEAR AS-IDLER (40/70-TEETH) | 1 | |
| 1B8705 | 14A KEY-WOODRUFF | 1 | |
| 2266052 | 14B BUSHING | 1 | |
| 2285813 | 15 GEAR AS-CRANKSHAFT (49-TEETH) | 1 | |
| 4N0684 | 15A DOWEL | 1 | |
| 3201237 | 16 GEAR AS-IDLER (37-TEETH) | 1 | |
| 7N2910 | 16A BUSHING | 1 | |
| 2306202 | 17 GEAR AS-IDLER (70/83-TEETH) | 1 | |
| 2249664 | 17A BUSHING | 1 | |
| 2473837 | 18 HOSE AS | 1 | |
| 3206198 | 19 GEAR AS-IDLER (57-TEETH) | 2 | |
| 2098621 | 19A BEARING | 1 | |
| 3201238 | 20 GEAR AS-PUMP (47-TEETH) | 1 | |
| 8T2153 | 20A SETSCREW-SOCKET (1/4-28X0.31-IN) | 1 | |
| 2569650 | 21 GEAR-PUMP (40-TEETH) | 2 | |
| 2569811 | 22 SHAFT-STUB | 2 | |
| 2570544 | 23 SHAFT | 2 | |
| 2595771 | 24 ADAPTER | 1 | |
| 2622954 | 25 ADAPTER | 1 | |
| 3316188 | 26 GEAR AS-CAMSHAFT (56-TEETH) | 2 | |
| 3235665 | PIN-DOWEL | 1 | |
| 2924486 | 27 SHAFT-STUB | 1 | |
| 2924487 | 28 RETAINER | 1 | |
| 2925517 | 29 TUBE AS | 1 | |
| 0310228 | 30 BOLT-12 POINT HEAD (1/2-13X3-IN) | 12 | |
| 0315085 | 31 BOLT-LOCKING (1/4-20X1-IN) | 6 | |
| 1178801 | 32 SEAL-O-RING | 2 | |
| 1641404 | 33 SPACER (10.67X16.95X23-MM THK) | 1 | |
| 2453804 | 34 BOLT (3/8-16X3.5-IN) | 1 | |
| 0S0509 | 35 BOLT (3/8-16X0.75-IN) | 1 | |
| 0S1590 | 36 BOLT (3/8-16X2-IN) | 12 | |
| 2A4639 | 37 BOLT (3/8-16X1.625-IN) | 1 | |
| 3B1915 | 38 BOLT (3/8-16X1.375-IN) | 12 | |
| 2147568 | 39 SEAL-O-RING | 2 | |
| 5E8771 | 40 SEAL-O-RING | 2 | |
| 5M2894 | 41 WASHER-HARD (10.2X18.5X2.5-MM THK) | 14 | |
| 5P4318 | 42 ELBOW | 1 | |
| 5P8245 | 43 WASHER-HARD (13.5X25.5X3-MM THK) | 18 | |
| 5P9299 | 44 CLIP (LOOP) | 2 | |
| 6J3913 | 45 BOLT-12 POINT HEAD (5/8-11X3.25-IN) | 12 | |
| 6K3607 | 46 CONNECTOR | 1 | |
| 5024034 | 47 SEAL-O-RING | 1 | |
| 6V4589 | 48 SEAL-O-RING | 2 | |
| 2977956 | 49 ELBOW (INCLUDES SCREEN FILTER) | 2 | |
| 6V5052 | 50 SEAL-O-RING | 1 | |
| 6V5141 | 51 SEAL-O-RING | 2 | |
| 7B3235 | 52 BOLT (1/2-13X1.375-IN) | 24 | |
| 9S1366 | 53 BOLT (1/2-13X2.5-IN) | 6 | |
| 2952682 | 54 SHAFT-STUB | 1 | |
| 8D0648 | 55 BOLT-12 POINT HEAD (1/2-13X4.5-IN) | 6 |
