342-2402 GEAR GP-REARS/N FHS1-UP

Group No: 342-2402

Part Number	Part Name	Qty
4N0848	1 SLEEVE-WEAR	1
4N7183	2 RING-RETAINING	2
5B0213	3 BOLT (3/8-16X2.375-IN)	6
5F7403	4 LOCKWASHER	2
5F7404	5 LOCKNUT-BEARING	2
5P1370	6 BEARING AS-ROLLER	2
0376874	7 STUD (1/4-20X1.772-IN)	1
1025861	8 PLATE-THRUST	2
1851497	9 GEAR AS-IDLER (79-TEETH)	1
2249664	9A BUSHING	1
2241219	10 SHAFT-STUB	1
2241220	11 PLATE	1
2241221	12 SHAFT-STUB	1
4755915	13 PLATE-SEALING	2
2249657	14 ADAPTER AS	2
4N0684	DOWEL	1
2266036	15 GEAR AS-IDLER (40/70-TEETH)	1
1B8705	KEY-WOODRUFF	1
2266052	15A BUSHING	1
2270159	16 SHAFT-STUB	1
2285813	17 GEAR AS-CRANKSHAFT (49-TEETH)	1
4N0684	DOWEL	1
2285814	18 GEAR AS-IDLER (37-TEETH)	2
2098621	18A BEARING	1
2291663	19 PLATE-THRUST	1
2306202	20 GEAR AS-IDLER (70/83-TEETH)	1
2249664	20A BUSHING	1
2098622	BUSHING	1
2532642	21 GEAR-HYDRAULIC PUMP DRIVE (48-TEETH)	1
2532643	22 GEAR-HYDRAULIC PUMP DRIVE (48-TEETH)	1
5410869	23 SHAFT-STUB	2
2969887	24 ADAPTER-PUMP	1
2969888	25 ADAPTER-PUMP	1
3316188	26 GEAR AS-CAMSHAFT (56-TEETH)	2
3235665	PIN-DOWEL	1
3520140	27 HOSE AS	2
0315085	28 BOLT-LOCKING (1/4-20X1-IN)	6
0S1616	29 BOLT (1/4-20X1-IN)	1
1178801	30 SEAL-O-RING	2
1A2029	31 BOLT (3/8-16X1.125-IN)	4
1T0720	32 BOLT-12 POINT HEAD (3/8-16X1.25-IN)	12
2147568	33 SEAL-O-RING	2
2385081	34 SEAL-O-RING	2
2453804	35 BOLT (3/8-16X3.5-IN)	1
2977956	36 ELBOW (INCLUDES SCREEN FILTER)	2
5E8771	37 SEAL-O-RING	2
5P4318	38 ELBOW	2
5P8429	39 SEAL-O-RING	2
6J3913	40 BOLT-12 POINT HEAD (5/8-11X3.25-IN)	12
5024034	41 SEAL-O-RING	1
7B3235	42 BOLT (1/2-13X1.375-IN)	8
7K6058	43 BOLT-12 POINT HEAD (1/2-13X2.5-IN)	12
8M2530	44 BOLT-12 POINT HEAD (1/2-13X1.25-IN)	16
