System And Components
272-9808 PRECOOLER GPS/N LEE1-599
Group No: 272-9808
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1616963 | 1 CLAMP | 2 | |
| 2451398 | 2 CONNECTOR | 1 | |
| 2451400 | 3 ELBOW | 1 | |
| 2645779 | 4 CLAMP AS (V-BAND) | 1 | |
| 8T0122 | NUT-FULL (1/4-28-THD) | 1 | |
| 2669800 | 5 DUCT | 1 | |
| 2698788 | 6 CLAMP-BAND | 4 | |
| 2720405 | 7 CORE AS (PRECOOLER) | 1 | |
| 2726141 | 8 HOSE | 1 | |
| 2726527 | 9 HOSE | 1 | |
| 2729851 | 10 STEM | 1 | |
| 2730204 | 11 HOSE | 1 | |
| 6V5063 | 12 SEAL-O-RING | 2 | |
| 6V5219 | 13 BOLT (M8X1.25X40-MM) | 4 | |
| 6V9027 | 14 SEAL-O-RING | 1 | |
| 8J1256 | 15 CLIP | 1 | |
| 8T0639 | 16 BOLT (M6X1X12-MM) | 1 | |
| 9M1974 | 17 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9X8267 | 18 WASHER (6.6X12X2-MM THK) | 1 |
