System And Components
289-2832 COMBUSTION GP-EXHAUSTS/N LEE623-667
Group No: 289-2832
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 6 | |
| 9S3232 | 2 CLIP | 1 | |
| 2256435 | 3 CLAMP-BAND | 1 | |
| 2284064 | 4 BRACKET | 1 | |
| 2775439 | 5 SPARK PLUG (ARD) | 1 | |
| 2856393 | 6 CLIP (LADDER) | 2 | |
| 2856395 | 7 CLIP (LADDER) | 1 | |
| 2890728 | 8 NUT (M8X1.25-THD) | 3 | |
| 2893107 | 9 GASKET | 1 | |
| 2900113 | 10 CLIP | 1 | |
| 2901392 | 11 SUPPORT AS | 1 | |
| 2901681 | 12 COMBUSTION GP-EXHAUST | 1 | |
| 2902102 | 13 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 2903930 | 14 BOLT (M8X1.25X55-MM) | 2 | |
| 2910505 | 15 WIRE AS | 1 | |
| 2841492 | SLEEVE (132-CM) | ||
| 2919951 | 16 TUBE AS | 1 | |
| 1562603 | 17 BOLT (M8X1.25X25-MM) | 1 | |
| 2901993 | 18 STRAP-CABLE | 5 | |
| 4P8134 | 19 CLIP (LADDER) | 2 | |
| 5M2894 | 20 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 6V5215 | 21 BOLT (M8X1.25X16-MM) | 1 | |
| 6V5222 | 22 BOLT (M8X1.25X85-MM) | 2 | |
| 6V8490 | 23 BOLT (M6X1X25-MM) | 2 | |
| 7X2619 | 24 BOLT (M6X1X10-MM) | 1 | |
| 9M1974 | 25 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 9X8256 | 26 WASHER (6.6X12X2-MM THK) | 1 | |
| 9X8267 | 27 WASHER (6.6X12X2-MM THK) | 2 | |
| 2886815 | 28 SENSOR GP-TEMPERATURE (FLAME BOUNDARY, EXHAUST 3)(EXHAUST) | 1 | |
| 2886820 | 29 SENSOR AS-TEMPERATURE (EXHAUST) | 1 |
