System And Components
382-7816 REGULATOR GP-TEMPERATURE -AFTERCOOLERS/N PYA1-UP
Group No: 382-7816
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N3872 | 1 SUPPORT | 1 | |
| 1W8129 | 2 SUPPORT (REAR) | 1 | |
| 2V4387 | 3 SPACER (10.312X25.4X23.11-MM THK) | 2 | |
| 7C9597 | 5 FLANGE | 4 | |
| 2162285 | 7 JOINT AS-TUBE | 2 | |
| 1274230 | SEAL | 2 | |
| 1539481 | 9 CLAMP AS | 8 | |
| 1539963 | 10 RING | 4 | |
| 1965052 | 11 CLIP (SLOT) | 2 | |
| 1965053 | 12 CLIP (TAB) | 2 | |
| 4947440 | 13 BRACKET | 1 | |
| 2166217 | 14 HOUSING & REGULATOR GP (AFTERCOOLER) | 1 | |
| 2686293 | 15 ELBOW | 1 | |
| 2686294 | 16 ADAPTER | 1 | |
| 2687733 | 17 FLANGE | 1 | |
| 2728396 | 18 CLAMP | 4 | |
| 2798984 | 19 CONNECTOR | 1 | |
| 2798985 | 20 CONNECTOR | 1 | |
| 2798986 | 21 CONNECTOR | 1 | |
| 2798987 | 22 BRACKET AS | 1 | |
| 2798988 | 23 TUBE | 1 | |
| 2798989 | 24 TUBE | 1 | |
| 2798990 | 25 TUBE | 1 | |
| 2798991 | 26 TUBE | 1 | |
| 2798992 | 27 SEAL-O-RING | 1 | |
| 2798993 | 28 CLAMP | 2 | |
| 0L1351 | 29 BOLT (3/8-16X0.875-IN) | 8 | |
| 0L1352 | 30 BOLT (3/8-16X3.25-IN) | 2 | |
| 1653931 | 31 BOLT (3/8-16X1.75-IN) | 6 | |
| 0S1588 | 32 BOLT (3/8-16X1.25-IN) | 8 | |
| 0S1590 | 33 BOLT (3/8-16X2-IN) | 10 | |
| 1653929 | 34 BOLT (3/8-16X1.5-IN) | 1 | |
| 0S1594 | 35 BOLT (3/8-16X1-IN) | 1 | |
| 0T0055 | 36 BOLT (3/8-16X4.25-IN) | 2 | |
| 1A5822 | 37 BOLT (1/2-13X2.75-IN) | 2 | |
| 2H3928 | 39 SEAL-O-RING | 1 | |
| 3B1915 | 40 BOLT (3/8-16X1.375-IN) | 4 | |
| 6V9027 | 41 SEAL-O-RING | 1 | |
| 3K0360 | 42 SEAL-O-RING | 1 | |
| 3S1223 | 43 SEAL-O-RING | 1 | |
| 8M9024 | 44 WASHER-HARD (10.2X22.5X5-MM THK) | 4 | |
| 4F7387 | 45 SEAL-O-RING | 1 | |
| 5B0841 | 47 BOLT (5/8-18X1.75-IN) | 4 | |
| 5B4399 | 48 SEAL-O-RING | 5 | |
| 5H8848 | 49 SEAL-O-RING | 4 | |
| 5M2894 | 50 WASHER-HARD (10.2X18.5X2.5-MM THK) | 41 | |
| 8T1919 | 52 SEAL-O-RING | 4 | |
| 9S4182 | 54 PLUG (7/16-20-THD) | 1 | |
| 9S8752 | 56 NUT-FULL (3/8-16-THD) | 11 | |
| 9X6458 | 57 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 1A2029 | 59 BOLT (3/8-16X1.125-IN) | 6 | |
| 9S8005 | 60 PLUG (3/4-16-THD) | 1 |
